CONTENTS Telephone: +39 0883 661 503 Fax: +39 0883 661 823 email: info@teco-europe.com web: www.teco-europe.com “Disclaimer” - TECO reserves the right to redesign its products, resulting in changes to specification and performance, at any time without notice and without liability to any person. - Adjustable Flow & Throw....................................................... - Adjustable Flow & Throw....................................................... - Pressure Compensating........................................................ - Pressure Compensating........................................................ - Adjustable Flow & Throw & Pressure Compensating......... - Adjustable Flow & Throw....................................................... - Pressure Compensating........................................................ - Pressure Compensating........................................................ Ottima™ 360° 8 Stream Drippers Ottima™ 180° 5 Stream Drippers Ottima™ 360° PC Spike 8 Stream Drippers Ottima™ 180° PC Spike 5 Stream Drippers Mini Bubbla 360° Umbrella Pattern Emitters Delta™ Drip Drip Emitters Delta™ Drip Spike PC Drip Emitter Mikra™ Drip PC Drip Emitter 2 3 4 4 5 6 7 8 Maxima™ 360° Vortex Sprays Maxima™ 360° PC Spike Vortex Sprays Idra™ Sprays Spray Jets Aquila™ Jet Spike Spray Spike Assemblies Idra™ Spike Spray Spike Assemblies Micro Sprays Aquila™ Jets Micro Sprays Aquila™ Jet PC Sprays Jets Single Piece Jets Micro Sprays Down Sprays & Stream Jets Open Frame Sprays Down Sprays & Stream Jets Open Frame Sprays - Adjustable Flow & Throw....................................................... - Pressure Compensating........................................................ - Adjustable Flow & Throw....................................................... - Adjustable Flow & Throw....................................................... - Adjustable Flow & Throw....................................................... - Caps & Bases.......................................................................... - Fixed Flow............................................................................... - Pressure Compensating........................................................ - Matched Precipitation............................................................ - Standard & Pressure Compensating.................................... - Shut-Off Adaptor , Down Spray 45° Assemblies ................ 9 10 11 12 12 13 14 16 18 19 20 Orbita Micro Sprinklers Standard, Inverted & Spikes Orbita Micro Sprinklers Standard, Inverted & Spikes Orbita PC Micro Sprinklers Orbita Micro Sprinklers Standard and Inverted Orbita Micro Sprinklers Inverted Sprinkler Assemblies Orbita Micro Sprinklers Standard and Inverted - Fixed Flow & Adjustable Flow............................................... - Fixed Flow & Adjustable Flow............................................... - Pressure Compensating........................................................ - Fixed Flow & Adjustable Flow............................................... - Fixed Flow .............................................................................. - Fixed Flow .............................................................................. 21 22 23 24 25 26 Micro Valves Testa Roja Valves Landscape Testa Roja Valves Agriculture Testa Roja Valves Agriculture - Barb & Thread Connections.................................................. - Barb & Thread Connections.................................................. - PE & PVC Pipe, Layflat and Tape Connections................... - Barb, Thread, Tape and Compression Connections........... 27 28 30 35 Filters & Pressure Reducers - Thread Connections............................................................. - Barb & Thread Connections................................................ 36 37 Ultra™ Stakes & Ground Hooks - Stakes & Stake Assemblies................................................... 38 Fittings Fittings Fittings Fittings Fittings Fittings Fittings - Micro Fittings, Adaptors, Nut & Tails.................................... - Rigid Risers............................................................................. - Ratchet Clamps & Accessories............................................. - Double Barb Drip-Line Connections..................................... - Tape Adaptors ........................................................................ - Accessories............................................................................. - Elbows, Tees Tape, Low Pressure Valves, Dripline Adapt.. 39 40 41 42 43 44 45 Drip Kits - Patio Kit & Vegetable Kit........................................................ 46 Controllers Controllers Controllers Dripperline Living Wall™ - Solar & Battery Operated Controllers................................... - Solar & Battery Operated Hose End Timers......................... - Blue Tooth Hose End Timer & Controller............................. - Micro-Line™........................................................................... - Living Wall™........................................................................... 47 48 49 50 51 Warranty - Conditions of Sale Limited Warranty.................................... 52 DRIPPERS SPRAYS SPRINKLERS VALVES FILTERS FITTINGS KITS DIG PRODUCTS STAKES WARRANTY TECO Srl Head Office Trav. SP 130 Trani - Andria km 1,800 76125 Trani (BT) ITALY B2B www.distrijet.ch 022 84 000 45
FEATURES and BENEFITS ● Rotation of the Ottima™ 360°cap allows simultaneous adjustment of flow rate and diameter of throw. Easy to increase or decrease the stream pattern. ● Gives a greater control of flow rate and diameter of throw compared to fixed flow emitters. ● Quick ON-OFF action. ● Four base options available, 4.5 mm Barb, 10-32 UNF MaleThread, 1/2” Female Thread and Spike. APPLICATIONS ● Use for watering plants in small or large pots, planter boxes and also shrubs and trees in garden beds and landscaped areas. PERFORMANCE DATA DRIPPERS PRESSURE (bar) FLOW (l/h) DIAMETER OF THROW (m) Adjustable to Maximum (approx) 20 Clicks 1.0 0 - 40 0 - 0.5 1.5 0 - 50 0 - 0.6 2.0 0 - 60 0 - 0.8 Tested 200 mm above Ground Level Recommended operating pressure 1.0 bar Ottima™ 360° Adjustable 8 Stream Drippers Ottima 360° Spike Ottima 360° In-Line Spike 2 Ottima™ 360° 1/2” Female Thread Ottima™ 360° 4.5 mm Barb Ottima™ 360° 10-32 UNF Thread DRIPPERS Ottima™ 360° PACKAGING Barb Thread Spike In-Line Spike 1/2” Thread Order Codes Packs 200016 200026 200034 204294 202054 Bulk 020001 020002 020003 020429 020205 Quantity per Bag Packs 100 100 25 25 25 Bulk 1000 1000 1000 1000 250 Bags per Carton Packs 65 65 40 40 70 Bulk 7 7 1 1 7 Weight per Carton (kg) Packs 12.3 14.2 6.9 6.9 9.4 Bulk 11.0 14.9 6.7 6.7 9.0 Base Inlet Connection 4.5 mm Barb 10-32 UNF Thread 4.5 mm Barb 4.5 mm Barb 1/2” Female Thread Dimensions Assembled (mm) Height 24 24 152 152 30 Width 20 20 42 38 27 Depth 16 16 16 16 27 Weight (g) 1.7 2.0 5.7 5.5 4.6 Material U.V. Stabilized Les Spécialistes des Métiers de l’Eau et du Paysage
PERFORMANCE DATA DRIPPERS PRESSURE (bar) FLOW (l/h) RADIUS OF THROW (m) Adjustable to Maximum (approx) 20 Clicks 1.0 0 - 40 0 - 0.38 1.5 0 - 50 0 - 0.52 2.0 0 - 60 0 - 0.65 Tested 200 mm above Ground Level Recommended operating pressure 1.0 bar Adjustable 5 Stream Drippers Ottima™ 180° PACKAGING Barb Thread Spike In-Line Spike 1/2” Thread Order Codes Packs 201146 201156 201164 204314 202064 Bulk 020114 020115 020116 020431 020206 Quantity per Bag Packs 100 100 25 25 25 Bulk 1000 1000 1000 1000 250 Bags per Carton Packs 65 65 40 40 70 Bulk 7 7 1 1 7 Weight per Carton (kg) Packs 12.3 14.2 6.9 6.9 9.4 Bulk 12.9 14.9 6.7 6.7 9.0 Base Inlet Connection 4.5 mm Barb 10-32 UNF Thread 4.5 mm Barb 4.5 mm Barb 1/2” Female Thread Dimensions Assembled (mm) Height 24 24 152 152 30 Width 20 20 42 38 27 Depth 16 16 16 16 27 Weight (g) 1.7 2.0 5.7 5.5 4.6 Material U.V. Stabilized Ottima™ 180° In-Line Spike Ottima™ 180° Spike Ottima™ 180° FEATURES and BENEFITS ● Rotation of the Ottima™ 180°cap allows simultaneous adjustment of flow rate and diameter of throw. Easy to increase or decrease the stream pattern. ● Gives a greater control of flow rate and diameter of throw compared to fixed flow emitters. ● Quick ON-OFF action. ● Four base options available, 4.5 mm Barb, 10-32 UNF MaleThread, 1/2” Female Thread and Spike. APPLICATIONS ● Use for watering plants in small or large pots, planter boxes and also shrubs and trees in garden beds and landscaped areas. Ottima™ 180° 4.5 mm Barb Ottima™ 180° 10-32 UNF Thread Ottima™ 180° 1/2” Female Thread 3 DRIPPERS B2B www.distrijet.ch 022 84 000 45
Pressure Compensating Stream Drippers Ottima™ Spike PC 180°, 20 lph In-Line Ottima™ Spike PC 360°, 30 lph End-Line Ottima™ Spike PC - 360° & 180° Cap Pattern 360°x 8 Stream 180°x 5 Stream Connection Type End-Line In-Line End-Line In-Line PACKAGING Colour and Flow Rate 30 l/h 40 l/h 30 l/h 20 l/h 30 l/h 40 l/h 20 l/h 30 l/h Order Codes Packs 203264 203274 204334 205114 204354 204364 205134 204374 Bulk 020326 020327 020433 020511 020435 020436 020513 020437 Quantity per Bag Packs 25 Bulk 1000 Bags per Carton Packs 40 Bulk 1 Weight per Carton (kg) Packs 7.9 Bulk 7.7 Base Inlet Connection 4.5 mm Barb Dimensions Assembled (mm) Height 152 Width 27 38 27 38 Depth 17 Weight (g) 9.5 Material U.V. Stabilized PERFORMANCE DATA Cap Patterns 180° x 5 Stream 360° x 8 Stream DRIPPERS COLOUR AND PRE-DEFINED FLOW RATE PRESSURE (bar) FLOW (l/h) RADIUS OF THROW (m) DIAMETER OF THROW (m) Black 20 l/h 1.5 21.6 0.18 2.0 21.9 0.20 2.5 22.8 0.20 3.0 23.6 0.20 Orange 30 l/h 1.5 31.1 0.38 0.25 2.0 31.8 0.40 0.26 2.5 30.9 0.40 0.26 3.0 31.4 0.40 0.26 Blue 40 l/h 1.5 36.9 0.48 0.35 2.0 38.4 0.50 0.36 2.5 39.8 0.50 0.36 3.0 42.0 0.50 0.36 Recommended Operating Pressure 1.5 bar to 3.0 bar - Tested 200 mm above Ground Level FEATURES and BENEFITS ● Pressure Compensating Spike emitters with pre-defined discharge rates that maintain uniform output flow rate and diameter of throw when the inlet pressure of the supply system varies. ● Two Spikes are available: End-Line and In-Line, Colour Coded for easy identification ● Two Caps available: Ottima™ 180°, 5 Stream and Ottima™ 360°, 8 Stream ● The End-Line Ottima™ Spike PC 180° is available in three discharge rates, 20 l/h (Black) 30 l/h (Orange) and 40 l/h (Blue). ● The In-Line Ottima™ Spike PC 180° is available with two discharge rates, 20 l/h (Black) and 30 l/h (Orange) ● The End-Line Ottima™ Spike PC 360° is available with two discharge rates, 30 l/h (Orange) and 40 l/h (Blue). ● The In-Line Ottima™ Spike PC 360° is available with one discharge rate, 30 l/h (Orange) APPLICATIONS ● Use for watering plants in small or large pots, garden beds and landscaped areas. 4 FILTRATION REQUIREMENTS ● Black, Orange and Blue Spikes: 130 microns (120 mesh) Ottima™ Spike PC - 360° & 180° DRIPPERS Les Spécialistes des Métiers de l’Eau et du Paysage
FEATURES and BENEFITS ● Rotation of the Mini Bubbla cap allows simultaneous adjustment of flow rate and diameter of throw. This action produces a uniform umbrella pattern that gently applies water to the root zone of the plant. ● Four base options available for the Adjustable Mini Bubbla 360°, 4.5 mm Barb, 10-32 UNF Male Thread, 1/2” Female Thread and 150 mm Spike. ● Cap rotation adjusts flow and radius. ● Effective watering at the root zone. ● Easy to regulate the water flow. ● The Mini Bubbla 360° PC Spike is available in one discharge rate, 75 l/h, colour coded (Red). APPLICATIONS ● Use for watering plants in small or large pots, garden beds, street trees and palms. PERFORMANCE DATA DRIPPERS PRESSURE (bar) FLOW (l/h) DIAMETER OF THROW (m) Adjustable to Maximum (approx) 18 Clicks 1.0 0 - 85 0 - 0.5 1.5 0 - 103 0 - 0.8 2.0 0 - 119 0 - 1.0 Recommended operating pressure 1.0 bar Mini Bubbla 360° PC Spike 75 l/h 1.5 68 0.30 2.0 75 0.30 2.5 78 0.40 3.0 79 0.40 Recommended operating pressure 1.5 bar to 3.0 Tested 200 mm above Ground Mini Bubbla 360° PACKAGING Adjustable Mini Bubbla 360° 75 l/h PC Barb Thread Spike 1/2” Thread Spike PC Order Codes Packs 201176 201186 201194 202084 204394 Bulk 020117 020118 020119 020208 020439 Quantity per Bag Packs 100 100 25 25 25 Bulk 1000 1000 1000 250 1000 Bags per Carton Packs 65 65 40 70 40 Bulk 7 7 1 7 1 Weight per Carton (kg) Packs 11.7 14.2 7.4 8.0 10.9 Bulk 12.2 14.9 7.2 7.7 10.7 Base Inlet Connection 4.5 mm Barb 10-32 UNF Thread 4.5 mm Barb 1/2” Female Thread 4.5 mm Barb Dimensions Assembled (mm) Height 25 25 153 31 155 Width 20 20 42 27 42 Depth 16 16 16 27 16 Weight (g) 1.6 2.0 6.2 3.8 9.7 Material U.V. Stabilized Mini Bubbla 360° 1/2” Female Thread Mini Bubbla 360° PC Spike Umbrella Pattern Emitters, Adjustable & PC 5 FILTRATION REQUIREMENTS ● Red Spike: 200 microns (80 mesh) Mini Bubbla 360° Drippers Mini Bubbla 360° 10-32 UNF Thread Mini Bubbla 180° 4.5 mm Barb Mini Bubbla 360° Spike DRIPPERS B2B www.distrijet.ch 022 84 000 45
FEATURES and BENEFITS ● Rotation of the key in the body adjusts the flow rate from 0 to 6 l/h at 100 kPa. Flow rate may be increased or decreased until final shut off. ● Turbulent flow path. ● Two key types available: 1. End-Line Adjustable 0-6 l/h key. (Black) 2. In-Line Adjustable 0-6 l/h key. (Brown) ● Two body types to choose from depending on application: 1. Standard body with 4 .5 mm inlet barb. 2. Spike with 4.5 mm inlet barb. ● May be turned “OFF” when not in use. APPLICATIONS ● May be used for vegetable patches, home gardens, nurseries, pots and shrubs. Delta™ Drip Spike End-Line Delta™ Drip Emitters PACKAGING Barb End-Line Spike End-Line Barb In-Line Spike In-Line Order Codes Packs 200916 200904 203936 203944 Bulk 020091 020090 020393 020394 Quantity per Bag Packs 100 25 100 25 Bulk 1000 1500 1000 1250 Bags per Carton Packs 70 50 70 50 Bulk 7 1 7 1 Weight per Carton (kg) Packs 13.4 7.0 13.4 7.0 Bulk 13.1 7.7 13.1 7.7 Base Inlet Connection 4.5 mm Barb 4.5 mm Barb 4.5 mm Barb 4.5 mm Barb Dimensions Assembled (mm) Height 17 127 17 127 mm Width 51 51 61 61 Depth 9 10 9 10 Weight (g) 1.72 4.63 1.8 4.7 Material U.V. Stabilized Delta™ Drip Spike In-Line PERFORMANCE DATA DRIPPERS PRESSURE (bar) FLOW (l/h) Adjustable to 6 l/h at 1.0 bar 0.5 0 - 4.1 0.75 0 - 5.1 1.0 0 - 6.0 1.25 0 - 6.8 1.5 0 - 7.5 Recommended operating pressure 1.0 bar FILTRATION REQUIREMENTS ● Drip Emitters: 100 microns (150 mesh) Adjustable Drip Emitter (Registered Design) 6 Delta™ Drip Delta™ Drip 4.5 mm Barb End-Line Delta™ Drip 4.5 mm Barb In-Line Drippers DRIPPERS Les Spécialistes des Métiers de l’Eau et du Paysage
Pressure Compensating Drip Emitters Delta™ Drip Spike PC Connection Type End-Line In-Line PACKAGING Colour and Flow Rate 2 l/h 4 l/h 8 l/h 2 l/h 4 l/h 8 l/h Order Codes Packs 202744 202754 202764 202774 202784 202794 Bulk 020274 020275 020276 020277 020278 020279 Quantity per Bag Packs 25 Bulk 1250 Bags per Carton Packs 50 Bulk 1 Weight per Carton (kg) Packs 11.6 11.8 Bulk 11.4 11.5 Base Inlet Connection 4.5 mm Barb Dimensions Assembled (mm) Height 144 Width 28 38 Depth 17 Weight (g) 8.3 8.4 Material U.V. Stabilized Delta™ Drip Spike PC 8 lph In-Line Delta™ Drip Spike PC 2 lph End-Line PERFORMANCE DATA DELTA™ Drip Spike PC End-Line & In-Line 2 l/h 4 l/h 8 l/h DRIPPERS PRESSURE (bar) FLOW (l/h) FLOW (l/h) FLOW (l/h) Pressure Compensating 1.0 1.84 4.31 7.40 1.5 1.94 3.97 7.30 2.0 1.99 3.85 7.45 2.5 2.03 3.82 7.84 3.0 1.98 3.72 8.02 Minimum Cross-section 0.6 x 0.8 0.8 x 0.95 1.0 x 1.1 Recommended Operating Pressure 1.0 bar to 3.0 bar FEATURES and BENEFITS ● Turbulent flow path pressure compensating drip emiters with pre-defined flow rates. ● Suit installations where slopes and changes of water pressure would otherwise require complex design systems and where uniform flow rates are required. ● Two Spike versions available. 1. End-Line with 4.5 mm Inlet Barb 2. In-Line with 4.5 mm Inlet & Outlet Barb ● Three flow rates available for each spike type, Colour coded for easy identification: 2 l/h (Red), 4 l/h (Black) and 8 l/h (Green) APPLICATIONS ● May be used for vegetable patches, home gardens, nurseries, balconies and patios. 7 FILTRATION REQUIREMENTS ● Drip Emitters: 100 microns (150 mesh) Delta™ Drip PC Drippers DRIPPERS B2B www.distrijet.ch 022 84 000 45
Mikra™ 1 l/h 4.5 mm Barb Pressure Compensating Drip Emitters PERFORMANCE DATA MIKRA™ Drip PC Button Drip Emitters DRIPPERS PRESSURE (bar) FLOW (l/h) 1 l/h 2 l/h 4 l/h 8 l/h Pressure Compensating 0.5 1.18 1.69 3.74 4.75 1.0 1.15 1.72 3.8 7.33 1.5 1.33 1.88 4.09 8.22 2.0 1.20 1.95 4.23 8.28 2.5 1.15 2.00 4.26 8,27 3.0 1.06 1.97 4.26 8.29 Minimum Cross-section 0.45 x 0.55 0.6 x 0.8 0.8 x 0.95 1.0 x 1.1 Recommended Operating Pressure 1.0 bar to 3.0 bar Mikra™ Drip PC Connection Type 4.5 mm Barb PACKAGING Colour and Flow Rate 1 l/h 2 l/h 4 l/h 8 l/h Order Codes Packs 201806 203876 203886 203896 Bulk 020180 020387 020388 020389 Quantity per Bag Packs 100 Bulk 1000 Bags per Carton Packs 75 Bulk 8 Weight per Carton (kg) Packs 16.8 Bulk 17.8 Base Inlet Connection 4.5 mm Barb Dimensions Assembled (mm) Height 26 Width 17.5 Depth 18.5 Weight (g) 2.0 Material U.V. Stabilized FEATURES and BENEFITS ● Turbulent flow path, pressure compensating drip emiters with pre-defined flow rates. ● Suit installations where slopes and changes of water pressure would otherwise require complex design systems and where uniform flow rates are required ● Self piercing 4.5 mm barb with sharp needle for quick and easy installation. ● Four flow rates are available. Colour coded for easy identification: 1 l/h (Brown), 2 l/h (Red), 4 l/h (Black) and 8 l/h (Green) APPLICATIONS ● May be used for vegetable patches, home gardens, nurseries, balconies and patios. FILTRATION REQUIREMENTS ● Drip Emitters: 100 microns (150 mesh) 8 Mikra™ 2 l/h 4.5 mm Barb Drippers Mikra™ Drip PC Mikra™ 4 l/h 4.5 mm Barb Mikra™ 8 l/h 4.5 mm Barb DRIPPERS Les Spécialistes des Métiers de l’Eau et du Paysage
FEATURES and BENEFITS ● Rotation of the Maxima™ 360°cap allows simultaneous adjustment of flow rate and diameter of throw. The ratchet clip action between the cap and the base allows the vortex pattern to be increased or decreased until final shut-off. ● Four base options available, 4.5 mm Barb, 10-32 UNF Male Thread, 1/2” Female Thread and 150 mm Spike. ● Vortex action distributes water evenly over the irrigated surface. APPLICATIONS ● Ideal for spot watering of plants in small and large pots or larger areas including garden beds and landscapes. PERFORMANCE DATA SPRAYS PRESSURE (bar) FLOW (l/h) DIAMETER OF THROW (m) Adjustable to Maximum (approx) 14 Clicks 1.0 0 - 52 0 - 1.7 1.5 0 - 65 0 - 2.8 2.0 0 - 74 0 - 3.4 Tested 200 mm above Ground Level Recommended operating pressure 1.0 bar Maxima™ 360° Spike Adjustable Vortex Sprays Maxima™ 360° PACKAGING BARB THREAD SPIKE 1/2” THREAD Order Codes Packs 200045 200055 200064 202074 Bulk 020004 020005 020006 020207 Quantity per Bag Packs 50 50 25 25 Bulk 1000 1000 1000 250 Bags per Carton Packs 100 100 40 70 Bulk 7 7 1 7 Weight per Carton (kg) Packs 14.2 16.8 7.9 8.2 Bulk 18.8 22.4 7.7 7.9 Base Inlet Connection 4.5 mm Barb 10-32 UNF Thread 4.5 mm Barb 1/2” Female Thread Dimensions Assembled (mm) Height 24 24 152 30 Width 20 20 42 27 Depth 16 16 16 27 Weight (g) 2.5 3.0 6.7 3.9 Material U.V. Stabilized 9 Maxima™ 360° SPRAYS Maxima 360° 4.5 mm Barb Maxima 360° 10-32 UNF Thread Maxima™ 360° 1/2” Female Thread B2B www.distrijet.ch 022 84 000 45
Maxima™ 360° Spike PC Pressure Compensating Vortex Spike Maxima™ 360° Spike PC Connection Type End-Line PACKAGING Colour and Flow Rate 30 l/h 40 l/h 45 l/h 50 l/h 60 l/h Order Codes Packs 204594 204604 204614 204624 204634 Bulk 020459 020460 020461 020462 020463 Quantity per Bag Packs 25 Bulk 1000 Bags per Carton Packs 40 Bulk 1 Weight per Carton (kg) Packs 11.4 Bulk 11.3 Base Inlet Connection 4.5 mm Barb Dimensions Assembled (mm) Height 155 Width 27 Depth 17 Weight (g) 10.3 Material U.V. Stabilized Maxima™ 360° Spike PC 50 lph End-Line Maxima™ 360° Spike PC 40 lph End-Line PERFORMANCE DATA MAXIMA ™ 360° Spike PC SPRAYS COLOUR AND PRE-DEFINED FLOW RATE PRESSURE (bar) FLOW (l/h) DIAMETER OF THROW (m) ORANGE 30 l/h 1.5 30.5 0.8 2.0 33.5 0.8 2.5 32.2 0.8 3.0 31.6 0.8 BLUE 40 l/h 1.5 35.5 1.0 2.0 38.3 1.1 2.5 39.0 1.1 3.0 40.9 1.1 VIOLET 45 l/h 1.5 38.7 1.4 2.0 44.5 1.5 2.5 45.3 1.6 3.0 48.1 1.6 GREEN 50 l/h 1.5 42.6 1.7 2.0 48.8 1.8 2.5 52.6 1.9 3.0 52.3 1.9 RED 60 l/h 1.5 48.8 2.7 2.0 56.6 2.8 2.5 62.8 2.9 3.0 66.3 3.0 Recommended Operating Pressure 1.5 bar to 3.0 bar - Tested 200 mm above Ground Level FILTRATION REQUIREMENTS ● Orange and Blue Spikes: 130 microns (120 mesh) ● Violet, Green and Red Spikes: 200 microns (80 mesh) FEATURES and BENEFITS ● Pressure Compensating End-Line Vortex spray spikes with pre-defined flow rates and 4.5 mm Inlet Barb. Ideal where uniform flow rates and constant diameter of throw are required. ● Five pre-defined flow rates are available. Colour coded for easy identification: 30 l/h (Orange), 40 l/h (Blue), 45 l/h (Violet), 50 l/h (Green) and 60 l/h (Red) APPLICATIONS ● May be used for vegetable patches, home gardens and nurseries. 10 SPRAYS Les Spécialistes des Métiers de l’Eau et du Paysage
Idra™ 90° Idra™ 180° Idra™ 360° PERFORMANCE DATA SPRAYS BASE OUTLET SIZE PRESSURE (bar) FLOW (l/h) Spray Pattern Radius of Throw (m) Diameter of Throw (m) 90° 180° 360° x 18 Hole Mini Vortex Micro Mist Adjustable to Maximum 1.5 mm 0.5 0 - 54 0 - 1.5 0 - 1.4 0 - 5.0 1.0 0 - 77 0 - 2.1 0 - 2.0 0 - 5.8 1.5 0 - 94 0 - 2.6 0 - 2.3 0 - 6.4 2.0 0 - 105 0 - 3.0 0 - 2.8 0 - 7.0 2.5 0 - 119 0 - 3.3 0 - 3.0 0 - 7.5 0.5 0 - 27 0 - 2.0 1.0 0 - 41 0 - 2.5 1.5 0 - 52 0 - 3.0 2.0 0 - 59 0 - 3.5 2.5 0 - 66 0 - 3.8 0.5 0 - 9 0 - 0.4 1.0 0 - 13 0 - 0.5 1.5 0 - 15 0 - 0.5 2.0 0 - 16 0 - 0.5 2.5 0 - 18 0 - 0.5 Tested 500 mm above Ground Level Recommended operating pressure 1.0 bar Idra™ Mini Vortex Idra™ Micro Mist Adjustable Spray Jets Idra™ Sprays RANGE Coloured Residential Range Black Professional Range Spray Pattern Cap Colour Black Blue Red Green Black Black Black Black Rotor Colour Blue Blue Blue Black Blue Black Black Black Base Colour Yellow Yellow Yellow Black Yellow Black Black Black Order Codes Packs 200085 200105 200125 201475 201485 200075 200095 200115 Bulk 020008 020010 020012 020147 020148 020007 020009 020011 Quantity per Bag Packs 50 50 50 50 50 50 50 50 Bulk 1000 1000 1000 1000 1000 1000 1000 1000 Bags per Carton Packs 100 100 100 100 100 100 100 100 Bulk 5 5 5 5 5 5 5 5 Weight per Carton (kg) Packs 13.9 13.9 13.9 13.9 13.9 13.9 13.9 13.9 Bulk 13.4 13.4 13.4 13.4 13.4 13.4 13.4 13.4 Base Inlet Connection 10-32 UNF Thread Dimensions Assembled (mm) Height 38 38 38 38 38 38 38 38 Width 22 22 22 22 22 22 22 22 Depth 15 15 15 15 15 15 15 15 Weight (g) 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5 Material U.V. Stabilized 11 Idra™ Sprays Sprays FEATURES and BENEFITS ● Rotation of the valve rotor allows simultaneous adjustment of flow rate and radius of throw. ● Available in 5 spray patterns: 90° Fan Spray, 180° Fan Spray, 360° x 18 Hole Stream Spray Mini Vortex and Micro Mist ● Two ranges available: Coloured residential range for easy spray pattern identification. Black professional range. APPLICATIONS ● Watering of landscaped areas. ● Easily adjusted to suit irregular shaped garden beds. SPRAYS B2B www.distrijet.ch 022 84 000 45
FEATURES and BENEFITS ● Pre-assembled Jet Spikes. Rotation of the Rotor allows simultaneous adjustment of flow rate and radius of throw. ● Available in three spray patterns: 90° Fan Spray, 180° Fan Spray and 360°x 18 Hole Stream Spray ● Spike lengths available: 200 mm and 310 mm for the Aquila Jet Spike and 310 mm for Idra Jet Spike ● Rigid Riser lengths: 200 mm for Aquila™ Jet Spike and 300 mm for the Idra™ Spike ● The Rigid Riser used with the Idra™ Spike may be raised or lowered inside the stake to suit the height of the plants being irrigated. ● Flexible PVC tube length: 500 mm APPLICATIONS ● General watering of landscaped areas. PERFORMANCE DATA SPRAYS PRESSURE (bar) FLOW (l/h) SPRAY PATTERN Diameter of Throw (m) Radius of Throw (m) 360° x 18 Hole 180° 90° BASE Adjustable to Maximum 1.5 mm 0.5 0 - 58 0 - 5.0 0 - 1.9 0 - 1.7 1.0 0 - 82 0 - 6.8 0 - 2.3 0 - 2.5 1.5 0 - 101 0 - 7.9 0 - 2.7 0 - 2.9 2.0 0 - 117 0 - 8.2 0 - 3.0 0 - 3.2 2.5 0 - 130 0 - 8.4 0 - 3.3 0 - 3.5 Recommended operating pressure 1.0 bar Spike Options Aquila™Jet Spike Idra™ Spike 200 mm Spike 310 mm Spike 310 mm Spike Spray Pattern Cap Colour Black Black Blue Red Base Colour Red Black Order Codes Packs 200372 200382 200392 200342 200352 200362 201642 201992 202002 Bulk 020037 020038 020039 020034 020035 020036 020164 020199 020200 Quantity per Bag Packs 10 10 10 10 10 10 10 10 10 Bulk 200 200 200 150 150 150 150 150 150 Bags per Carton Packs 20 20 20 15 15 15 15 15 15 Bulk 1 1 1 1 1 1 1 1 1 Weight per Carton (kg) Packs 9.5 9.5 9.5 8.2 8.2 8.2 8.3 8.3 8.3 Bulk 9.2 9.2 9.2 8.0 8.0 8.0 8.1 8.1 8.1 Inlet Connection 4.5 mm Barb Dimensions Assembled (mm) Height 400 510 Max extension - 595 Width 25.2 25.2 25.2 Depth 17 17 17 Weight (g) 41.2 47.2 47.6 Material U.V. Stabilized Idra™ Spike Rigid Riser may be raised or lowered inside the stake to suit plant heights Adjustable Spray Spikes Aquila™ Jet Spke 12 SPRAYS Aquila™ Jet Spike (Registered Design) & Idra™ Jet Spike Les Spécialistes des Métiers de l’Eau et du Paysage
90° 180° 360° x 18 Hole 180° 360° x 18 Hole 180° Flat Traj. Caps and Bases Micro Spray Caps and Bases PACKAGING Caps Winged Jet Bases Black Blue Red Black Brown Blue Green Red Orange Grey White 90° 180° 360° 180° 360° 180° F/T Order Codes Packs 100176 100186 100196 100236 100246 104446 100516 100606 100616 100626 100636 100646 100656 100666 Bulk 010017 010018 010019 010023 010024 010444 010051 010060 010061 010062 010063 010064 010065 010066 Quantity per Bag Packs 100 100 Bulk 1000 1000 Bags per Carton Packs 500 320 Bulk 50 30 Weight per Carton (kg) Packs 16.0 22.1 Bulk 13.9 19.5 Base Inlet Connection “FAST” Thread Dimensions (mm) Height 9.4 9.4 8.3 9.4 8.3 9.4 22 Width 8 16 Depth 8 8 Weight (g) 0.24 0.57 Material U.V. Stabilized FEATURES and BENEFITS ● Caps available in three spray patterns ● 90° Fan Spray - Cap colour - Black ● 180° Fan Spray - Cap colour - Black or Blue ● 180° Fan Spray (Flat Trajectory) - Cap colour - Red ● 360° x 18 Hole Stream Spray - Cap colour - Black or Red. ● Eight colour coded bases with “FAST” thread for quick and easy installation. ● A large range of flow rates may be achieved at different operating pressures. ● Base colour identifies flow rate. ● Caps and bases may be ordered separately. APPLICATIONS ● Ideal for landscaped gardens and garden beds. Winged Jet Bases with “FAST” Thread Black Brown Blue Green Red Orange Grey White 0.8 mm 0.9 mm 1.0 mm 1.3 mm 1.5 mm 1.8 mm 2.0 mm 2.3 mm 13 Micro Sprays SSPpRraAyYsS B2B www.distrijet.ch 022 84 000 45
Micro Sprays Aquila™ Jet Spray Assemblies PACKAGING Assembled Aquila™ Jet Winged Bases with“FAST” Thread Mini Vortex Micro Mist Black Brown Blue Green Red Orange Grey White CAP COLOURS AND SPRAY PATTERNS Order Codes Packs 200406 200436 200466 200496 200526 200556 200586 200616 Bulk 020040 020043 020046 020049 020052 020055 020058 020061 90° Packs 200416 200446 200476 200506 200536 200566 200596 200626 Bulk 020041 020044 020047 020050 020053 020056 020059 020062 180° Packs 200426 200456 200486 200516 200546 200576 200606 200636 Bulk 020042 020045 020048 020051 020054 020057 020060 020063 360° x 18 Hole Packs 200646 200666 200686 200706 200726 200746 200766 200786 Bulk 020064 020066 020068 020070 020072 020074 020076 020078 180° Packs 200656 200676 200696 200716 200736 200756 200776 200796 Bulk 020065 020067 020069 020071 020073 020075 020077 020079 360° x 18 Hole Packs 204096 204106 204116 204126 204136 204146 204156 204166 Bulk 020409 020410 020411 020412 020413 020414 020415 020416 180° Flat Trajectory Packs 201466 205026 THE HEIGHT OF THE AQUILA™ JET SPRAYS MAY VARY SLIGHTLY DEPENDING ON BASE AND CAP SELECTED Bulk 020146 020502 Quantity per Bag Packs 100 Bulk 1000 Bags per Carton Packs 210 Bulk 22 Weight per Carton (kg) Packs 17.2 Bulk 17.1 Base Inlet Connection “FAST” Thread Dimensions Assembled (mm) Height 26 Width 16.2 Depth 7.7 Weight (g) 0.72 Material U.V. Stabilized Mini Vortex Micro Mist 90° 180° 360° x 18 Hole FEATURES and BENEFITS ● Two Piece micro sprays with excellent watering patterns that distribute water evenly over the irrigated surface. ● Optimum performance is achieved at low operating pressures. ● Winged bases are easy to install by hand, eliminating the need for tools. ● Four spray patterns available for the Aquila™Jet Winged Bases. ● 90° Fan Spray - Cap colour - Black ● 180° Fan Spray - Cap colour - Black or Blue ● 180° Flat Trajectory Fan Spray - Cap colour - Red ● 360° x 18 Hole Stream Spray - Cap colour - Black or Red. ● Eight colour coded bases with “FAST” thread for quick and easy installation. Base colour identifies flow rate. ● Aquila™Jet Mini Vortex ( the vortex action generated inside the cap distributes the water evenly over the wetted surface. ● Aquila™Jet Micro Mist (ideal for cooling operations). APPLICATIONS ● Landscaped areas and garden beds. Ideal where fixed flow rates are required at specified operating pressures. 14 SPRAYS Aquila™ Jet Les Spécialistes des Métiers de l’Eau et du Paysage
Micro Sprays Aquila™ Jet Sprays PERFORMANCE DATA Spray Patterns 90° 180° 180° Flat Trajectory 360° x 18 Hole Mini Vortex Micro Mist MICRO SPRAYS BASE COLOUR AND JET OUTLET SIZE PRESSURE (bar) FLOW RATE (l/h) RADIUS OF THROW (m) DIAMETER OF THROW (m) BLACK 0.8 mm 0.5 16 1.1 1.3 0.80 2.6 1.0 23 1.6 1.5 1.00 3.5 1.5 28 2.0 1.7 1.10 4.3 2.0 32 2.3 1.8 1.20 4.9 2.5 36 2.6 2.0 1.25 5.4 BROWN 0.9 mm 0.5 22 1.3 1.4 0.90 3.0 1.0 31 1.8 1.6 1.10 4.0 1.5 38 2.3 1.8 1.20 4.8 2.0 44 2.6 2.0 1.30 5.5 2.5 49 2.9 2.2 1.35 6.0 BLUE 1.0 mm 0.5 27 1.4 1.5 1.00 3.7 1.0 36 2.0 1.8 1.15 4.6 1.5 47 2.4 2.0 1.30 5.4 2.0 54 2.8 2.2 1.40 6.0 2.5 61 3.1 2.4 1.50 6.6 GREEN 1.3 mm 0.5 42 1.6 1.7 1.05 4.9 1.0 60 2.2 2.0 1.20 5.7 1.5 74 2.6 2.3 1.35 6.5 2.0 86 3.0 2.6 1.45 7.2 2.5 95 3.3 2.8 1.55 7.7 RED 1.5 mm 0.5 58 1.7 1.9 1.15 5.1 1.0 82 2.3 2.3 1.30 6.0 1.5 101 2.7 2.7 1.40 6.7 2.0 117 3.1 3.0 1.50 7.4 2.5 130 3.5 3.3 1.60 8.0 ORANGE 1.8 mm 0.5 74 1.8 2.1 1.25 5.2 1.0 109 2.4 2.6 1.35 6.1 1.5 133 2.8 3.0 1.45 6.8 2.0 154 3.2 3.3 1.55 7.5 2.5 172 3.6 3.6 1.65 8.1 GREY 2.0 mm 0.5 87 1.9 2.2 1.30 5.3 1.0 124 2.5 2.7 1.55 6.2 1.5 154 3.0 3.1 1.75 6.9 2.0 179 3.4 3.5 1.90 7.6 2.5 199 3.7 3.8 2.10 8.2 WHITE 2.3 mm 0.5 105 2.0 2.3 1.35 5.4 1.0 150 3.6 2.8 1.70 6.3 1.5 184 3.1 3.2 2.05 7.0 2.0 208 3.5 3.6 2.30 7.7 2.5 224 3.8 3.9 2.50 8.3 MINI VORTEX 0.5 27 2.0 1.0 41 2.5 1.5 52 3.0 2.0 59 3.5 2.5 66 3.8 MICRO MIST 0.5 9 0.4 1.0 13 0.5 1.5 15 0.5 2.0 16 0.5 2.5 18 0.5 PERFORMANCE GRAPH Tested 200 mm above Ground Level Recommended operating pressure 1.0 bar 90° 180° 360° x 18 Hole Optimum performance is achieved at low operating pressures as indicated in the table below by the blue shaded rows. FILTRATION REQUIREMENTS ● Black, Brown, Blue and Mist Bases: 130 microns (120 mesh) ● Green, Red, Orange, Grey, White and Vortex Bases: 200 microns (80 mesh) 15 Aquila™ Jets SSPpRraAyYsS B2B www.distrijet.ch 022 84 000 45
FEATURES and BENEFITS ● Pressure Compensating Spray Jets with excellent watering patterns and pre-defined flow rates. Ideal where uniform flow rates and constant diameter and radius of throw are required. Best performance is achieved between 1.5 bar and 3.0 bar. ● Six colour coded PC bases with pre-defined flow rates. Colour identifies flow rate. 20 l/h (Black), 30 l/h (Orange), 40 l/h (Blue) 50 l/h (Violet), 55 l/h (Green) and 80 l/h (Red) ● Four Spray Patterns available: 90° Fan Spray, Cap colour (Black) 180° Fan Spray, Cap colour (Black & Blue) 180° Flat Trajectory Fan Spray, Cap Colour Red)) 360° x 18 Hole Spray, Cap colour (Black & Red) ● 10-32 UNF Thread connection. APPLICATIONS ● Watering of landscaped areas and garden beds. Aquila™ Jet PC Spray Assemblies Colour Coded Bases Colour Black Orange Blue Violet Green Red Flow Rate 20 l/h 30 l/h 40 l/h 50 l/h 55 l/h 80 l/h Outlet Size (mm) 0.90 1.25 1.30 1.45 1.55 1.65 PACKAGING CAP COLOURS AND SPRAY PATTERNS Order Codes Packs 202805 202815 202825 202835 202845 202855 Bulk 020280 020281 020282 020283 020284 020285 90° Packs 202865 202875 202885 202895 202905 202915 Bulk 020286 020287 020288 020289 020290 020291 180° Packs 202945 202955 202965 202975 Bulk 020294 020295 020296 020297 360°x 18 Hole Packs 202985 202995 203005 203015 203025 203035 Bulk 020298 020299 020300 020301 020302 020303 180° Packs 203065 203075 203085 203095 Bulk 020306 020307 020308 020309 360°x 18 Hole Packs 204855 204865 204875 204885 204895 204905 Bulk 020485 020486 020487 020488 020489 020490 180° Flat Trajectory Quantity per Bag Packs 50 THE HEIGHT OF THE AQUILA™ JET PC SPRAYS MAY VARY SLIGHTLY DEPENDING ON BASE AND CAP SELECTED Bulk 1000 Bags per Carton Packs 100 Bulk 5 Weight per Carton (kg) Packs 19.0 Bulk 18.5 Base Inlet Connection 10-32 UNF Thread Dimensions Assembled (mm) Height 41 Width 18 Depth 17 Weight (g) 3.5 Material U.V. Stabilized Pressure Compensating Sprays FILTRATION REQUIREMENTS ● Black, Orange and Blue Bases: 130 microns (120 mesh) ● Violet, Green and Red Bases: 200 microns (80 mesh) 180° 360° x 18 Hole 16 SPRAYS Aquila™ Jet PC Les Spécialistes des Métiers de l’Eau et du Paysage
Aquila™ Jet PC Sprays METRIC PERFORMANCE DATA Spray Patterns 90° 180° 180° Flat Trajectory 360° x 18 Hole PRESSURE COMPENSATING SPRAYS BASE COLOUR AND FLOW RATE PRESSURE (bar) FLOW RATE (l/h) RADIUS OF THROW (m) DIAMETER OF THROW (m) BLACK 20 l/h 1.5 20.1 1.7 1.7 1.0 2.0 21.5 1.8 1.8 1.0 2.5 22.3 1.8 1.8 1.0 3.0 23.7 1.8 1.8 1.0 ORANGE 30 l/h 1.5 33.4 1.8 1.8 1.0 2.0 34.2 1.8 1.8 1.1 2.5 32.9 1.8 1.8 1.1 3.0 32.0 1.8 1.8 1.1 BLUE 40 l/h 1.5 38.1 1.8 1.8 1.1 3.6 2.0 41.2 1.9 1.9 1.2 3.8 2.5 41.6 1.9 1.9 1.2 3.8 3.0 43.2 1.9 1.9 1.2 3.8 VIOLET 50 l/h 1.5 46.0 1.9 1.9 1.2 3.8 2.0 49.4 1.9 2.0 1.2 4.0 2.5 48.6 1.9 2.0 1.2 4.0 3.0 49.6 1.9 2.0 1.2 4.0 GREEN 55 l/h 1.5 53.2 2.0 2.0 1.2 4.2 2.0 57.1 2.1 2.2 1.3 4.4 2.5 58.4 2.2 2.2 1.3 4.4 3.0 56.2 2.2 2.2 1.3 4.4 RED 80 l/h 1.5 68.0 2.5 2.2 1.3 5.4 2.0 78.9 2.6 2.4 1.3 5.8 2.5 84.8 2.8 2.5 1.3 6.0 3.0 84.2 2.8 2.5 1.3 6.0 PERFORMANCE GRAPH Tested 200 mm above Ground Level Recommended operating pressure 1.5 bar to 3.0 bar FEATURES and BENEFITS ● Pressure Compensating Spray Jets with excellent watering patterns and pre-defined flow rates that distribute water evenly over the irrigated surface whilst maintaining constant diameter and radius of throw. This ensures efficient watering of the surface being irrigated. 180° 360° x 18 Hole 90° Pressure Compensating Sprays 90° 17 Aquila™ Jet PC SSPpRraAyYsS B2B www.distrijet.ch 022 84 000 45
Micro Sprays Single Piece Micro Sprays PACKAGING Blue Multi-Coloured Spray Pattern 90° 180° 360° Strip 90° 180° 360° Strip Order Codes Packs 100926 100936 100946 100956 101186 101196 101206 101216 Bulk 010092 010093 010094 010095 010118 010119 010120 010121 Quantity per Bag Packs 100 Bulk 1000 Bags per Carton Packs 250 Bulk 25 Weight per Carton (kg) Packs 17.5 Bulk 16.4 Base Inlet Connection “FAST” Thread Dimensions (mm) Height 26 Width 16.2 Depth 7.7 Weight (g) 0.6 Material U.V. Stabilized 90° 180° 360° Strip 90° 180° 360° Strip FEATURES and BENEFITS ● Single Piece micro sprays that distribute water evenly over the irrigated surface. Optimum performance and “matched precipitation” is achieved at 1 bar operating pressure. Winged bases with “FAST” thread are easy to install by hand eliminating the need for tools. ● Two colour coded sets, Blue and Multi-Coloured. Four spray patterns available per set. ● 90° Fan Spray ● 180° Fan Spray ● 360° Fan Spray ● Strip Spray APPLICATIONS ● Watering of landscaped areas and garden beds. Single Piece Jets SINGLE PIECE MICRO SPRAYS Blue Multi-Coloured Spray Pattern 90° 180° 360° Strip 90° 180° 360° Strip Outlet Size 0.9 mm 1.2 mm 1.8 mm 1.2 mm 1.0 mm 1.4 mm 1.9 mm 1.4 mm Pressure (bar) Flow (l/h) Radius of Throw (m) Flow (l/h) Radius of Throw (m) Flow (l/h) Diameter of Throw (m) Flow (l/h) Diameter of Throw (m) Flow (l/h) Radius of Throw (m) Flow (l/h) Radius of Throw (m) Flow (l/h) Diameter of Throw (m) Flow (l/h) Diameter of Throw (m) 0.5 16 0.9 36 1.0 75 2.1 36 2.2 21 1.2 43 1.4 85 2.8 43 2.9 1.0 24 1.0 51 1.1 101 2.2 51 2.4 29 1.4 60 1.6 117 3.0 60 3.2 1.5 29 1.1 63 1.3 123 2.3 63 2.6 35 1.5 75 1.7 143 3.2 75 3.5 PERFORMANCE GRAPH Tested 200 mm above Ground Level Recommended operating pressure 100 kPa 18 SPRAYS Single Piece Spray Jets Les Spécialistes des Métiers de l’Eau et du Paysage
Standard & Pressure Compensating Sprays 12 Stream Flat Jet PC 8 Stream Jet PC Inverted Down Spray Standard Down Spray PC 30 l/h FEATURES and BENEFITS ● The strong “C” frame design allows for excellent water distribution uniformity. ● Two base types are available: Standard Base and Pressure Compensating Base. ● Five color coded Standard Bases. ● Six color coded Pressure Compensating Bases. ● Base color identifies the flow rate. ● Standard Bases and Pressure Compensating Bases may be combined with any Down Spray or Stream Jet. ● Assemblies made to order. APPLICATIONS ● Ideal garden beds, landscapes, vegetable gardens and agricultural applications. DOWN SPRAYS & STREAM JETS Standard Bases Pressure Compensating Bases Base Colour Black Brown Blue Green Red Black Orange Blue Violet Green Red Base Outlet Size (mm) 0.8 0.9 1.0 1.3 1.5 0.90 1.25 1.30 1.45 1.55 1.65 Flow Rate 20 l/h 30 l/h 40 l/h 50 l/h 55 l/h 80 l/h PACKAGING SPRAY & JET PATTERNS Order Codes Packs 204915 204925 204935 204945 204955 205844 205854 205864 205874 205884 205894 Bulk 020491 020492 020493 020494 020495 020584 020585 020586 020587 020588 020589 Down Spray 22° Packs 205715 205725 205735 205745 205755 205764 205774 205784 205794 205804 205814 Bulk 020571 020572 020573 020574 020575 020576 020577 020578 020579 020580 020581 12 Stream Flat Jet Packs 205155 205165 205175 205185 205195 205204 205214 205224 205234 205244 205254 Bulk 020515 020516 020517 020518 020519 020520 020521 020522 020523 020524 020525 8 Stream Jet Packs 211745 211755 211765 211775 211785 211824 211834 211844 211854 211864 Bulk 021174 021175 021176 021177 021178 021182 021183 021184 021185 021186 Down Spray 45° Quantity per Bag Packs 50 25 Bulk 500 500 Bags per Carton Packs 120 100 Bulk 12 5 Weight per Carton (kg) Packs 13.8 13.3 Bulk 13.1 12.8 Base Inlet Connection “FAST” Thread 10-32 UNF Thread Dimensions Assembled (mm) Height 41 41 Width 33 33 Depth 12 12 Weight (g) 2.0 4.7 Material U.V. Stabilized FILTRATION REQUIREMENTS ● Black, Orange and Blue Bases: 130 microns (120 mesh) ● Violet, Green and Red Bases: 200 microns (80 mesh) 19 Down Sprays & Stream Jets SSPpRraAyYsS B2B www.distrijet.ch 022 84 000 45
SPRAYS Down Sprays & Stream Jets Shut-Off Adaptor Spray Assemblies DOWN SPRAYS 45° Standard Bases Base Colour Black Brown Blue Green Red Base Outlet Size (mm) 0.8 0.9 1.0 1.3 1.5 Nominal Flow Rate at 1.5 bar (l/h) 28 38 47 74 101 PACKAGING SPRAY PATTERN Order Codes Packs 212644 212654 212664 212674 212684 Bulk 021264 021265 021266 021267 021268 Down Spray 45° Quantity per Bag Packs 25 Bulk TBA Bags per Carton Packs TBA Bulk TBA Weight per Carton (kg) Packs TBA Bulk TBA Base Inlet Connection Barb 4.5 mm Dimensions Assembled (mm) Height 331 Width 33 Depth 14 Weight (g) 30 Material U.V. Stabilized FEATURES and BENEFITS ● The strong “C” frame design allows for excellent water distribution uniformity. ● Five color coded Standard Bases. ● Base color identifies the flow rate. ● The Standard Bases are combined with the Down Spray 45°, the Shut-Off Tube Adaptor, Steel Spike and Flexible Tube for easy and rapid installation. ● Assemblies made to order. APPLICATIONS ● Ideal garden beds, landscapes, vegetable gardens and agricultural applications. FILTRATION REQUIREMENTS ● Black, Brown, and Blue Bases: 130 microns (120 mesh) ● Green and Red: 200 microns (80 mesh) 20 Les Spécialistes des Métiers de l’Eau et du Paysage
Down Sprays and Stream Jets PERFORMANCE DATA Spray Patterns Pattern Down Spray Down Spray 12 Stream Flat Jet 8 Stream Jet Inverted 8 Stream Jet Trajectory 18° 45° 0° 22° 22° Frame Colour Black Green Black Black Black Height Tested Tested 0.5 m above Ground Level Tested 0.8 m above Ground Level STANDARD BASES STANDARD BASES COLOUR AND BASE OUTLET SIZE PRESSURE (bar) FLOW RATE (l/h) DIAMETER OF THROW (m) BLACK 0.8 mm 0.5 16 1.8 0.1 2.6 4.0 2.4 1.0 23 1.9 0.3 3.4 4.2 2.7 1.5 28 1.9 1.0 4.0 4.4 2.9 2.0 32 2.0 1.0 4.4 4.6 3.1 2.5 36 2.0 1.0 4.6 4.6 3.2 BROWN 0.9 mm 0.5 22 1.8 0.3 3.0 4.4 3.0 1.0 31 2.0 1.0 3.8 4.6 3.4 1.5 38 2.1 1.0 4.4 4.7 3.7 2.0 44 2.1 1.0 4.7 4.8 3.8 2.5 49 2.2 1.0 4.9 4.9 3.9 BLUE 1.0 mm 0.5 27 1.9 1.0 3.8 4.6 3.1 1.0 36 2.1 1.0 4.6 4.8 3.6 1.5 47 2.2 1.0 5.2 4.9 3.9 2.0 54 2.3 1.0 5.6 5.0 4.1 2.5 61 2.4 1.0 5.8 5.1 4.2 GREEN 1.3 mm 0.5 42 2.0 1.0 4.2 6.8 3.4 1.0 60 2.2 1.0 5.2 7.0 4.0 1.5 74 2.3 1.0 5.9 7.3 4.4 2.0 86 2.4 1.0 6.4 7.4 4.6 2.5 95 2.5 1.0 6.7 7.5 4.7 RED 1.5 mm 0.5 58 2.5 1.0 4.5 7.4 3.8 1.0 82 2.7 1.0 5.4 7.9 4.4 1.5 101 2.8 1.0 6.1 8.3 4.8 2.0 117 2.9 1.0 6.6 8.6 5.0 2.5 130 3.0 1.0 6.9 8.8 5.1 Recommended operating pressure 1.5 bar PRESSURE COMPENSATING BASES PRESSURE COMPENSATING BASES COLOUR AND FLOW RATE PRESSURE (bar) FLOW RATE (l/h) Down Spray 18° Down Spray 45° 12 Stream Flat Jet 0° 8 Stream Jet 22° Inverted 8 Stream Jet 22 BLACK 20 l/h 1.5 20.1 1.8 2.8 3.8 2.3 2.0 21.5 1.8 2.9 3.9 2.4 2.5 22.3 1.8 2.9 4.0 2.4 3.0 23.7 1.8 2.9 4.0 2.4 ORANGE 30 l/h 1.5 33.4 1.9 1.0 3.2 4.6 2.5 2.0 34.2 1.9 1.0 3.3 4.7 2.6 2.5 32.9 1.9 1.0 3.2 4.7 2.6 3.0 32.0 1.9 1.0 3.2 4.7 2.6 BLUE 40 l/h 1.5 38.1 2.0 1.0 3.4 5.4 2.7 2.0 41.2 2.0 1.0 3.4 5.5 2.8 2.5 41.6 2.0 1.0 3.4 5.6 2.8 3.0 43.2 2.0 1.0 3.4 5.6 2.8 VIOLET 50 l/h 1.5 46.0 2.1 1.0 3.6 6.2 3.0 2.0 49.4 2.1 1.0 3.6 6.3 3.1 2.5 48.6 2.1 1.0 3.6 6.4 3.1 3.0 49.6 2.1 1.0 3.6 6.4 3.1 GREEN 55 l/h 1.5 53.2 2.2 1.0 3.8 6.8 3.4 2.0 57.1 2.2 1.0 3.9 7.0 3.5 2.5 58.4 2.2 1.0 4.0 7.1 3.5 3.0 56.2 2.2 1.0 4.0 7.1 3.5 RED 80 l/h 1.5 68.0 2.4 1.0 4.0 7.0 3.6 2.0 78.9 2.4 1.0 4.2 7.2 3.7 2.5 84.8 2.5 1.0 4.4 7.3 3.8 3.0 84.2 2.5 1.0 4.6 7.4 3.9 Recommended operating pressure 1.5 bar to 3.0 bar 12 Stream Flat Jet PC 12 Stream Flat Jet Stnd Down Spray Standard Down Spray PC 8 Stream Jet Standard 8 Stream Jet PC Inverted Standard & Pressure Compensating Sprays 21 SPRAYS Down Sprays & Stream Jets Down Spray PC 30 l/h B2B www.distrijet.ch 022 84 000 45
Micro Sprinklers Orbita Micro Sprinklers Standard Inverted Adjustable Spike 200 mm 310 mm Base Colour Brown Blue Green Red Orange Grey Brown Blue Green Red Black Yellow Red Red Base Outlet Size (mm) 0.9 1.0 1.3 1.5 1.8 2.0 0.9 1.0 1.3 1.5 0 to 1.5 0 to 1.5 0 to 1.5 0 to 1.5 PACKAGING Order Codes Packs 201035 201045 201055 201065 201075 201085 201105 201115 201125 201135 201394 201404 201552 201562 Bulk 020103 020104 020105 020106 020107 020108 020110 020111 020112 020113 020139 020140 020155 020156 Quantity per Bag Packs 50 50 25 10 10 Bulk 500 500 500 200 150 Bags per Carton Packs 120 120 100 20 15 Bulk 12 12 5 1 1 Weight per Carton (kg) Packs 15.5 15.6 12.1 9.9 8.6 Bulk 13.9 15.1 11.5 9.6 8.4 Base Inlet Connection “FAST” Thread “FAST” Thread 10-32 UNF Thread 4.5 mm Barb Dimensions Assembled (mm) Height 41 41 53 415 525 Width 33 33 33 33 33 Depth 12 12 23 23 23 Weight (g) 2.3 2.3 4.0 43.5 47.1 Material U.V. Stabilized Standard Inverted Adjustable FEATURES and BENEFITS ●The Strong “C” frame design allows for excellent water distribution uniformity. ● During rotation the spinner is supported between two bearings. ● The spinner on the inverted model has a cover that protects the bottom bearing from dust. ● Four Orbita micro sprinkler models available: Standard, Inverted, Adjustable and Spike. ● Six colour coded bases to choose from for the Standard model. ● Four colour coded bases for the Inverted model. ● Base colour identifies the flow rate. ● Two Adjustable models available: 1. Black Base with a Black Rotor 2. Yellow Base with a Blue Rotor. ● The Spike is a pre-assembled model for quick and easy installation with a Red Base, an adjustable rotor for flow and throw control, 500 mm flexible tube and 4.5 mm Joiner. There are two spike lengths to choose from, 200 mm and 310 mm. APPLICATIONS ● Ideal for large areas that include garden beds, landscapes, vegetable gardens and agricultural applications. 22 Orbita Micro Sprinklers SPRINKLERS Les Spécialistes des Métiers de l’Eau et du Paysage
Micro Sprinklers Adjustable Black Base - Black Rotor Standard Blue Base Inverted Red Base Adjustable Yellow Base - Blue Rotor Standard Red Base Inverted Green Base Micro Sprinklers PERFORMANCE DATA Standard Inverted Spike Adjustable 200 mm 310 mm Tested 0.2 m above Ground Level Tested 0.8 m above Ground Level Tested 2 m above Ground Level Tested 0.3 m above Ground Level Tested 0.4 m above Ground Level Tested 0.2 m above Ground Level FIXED FLOW BASE COLOUR AND BASE OUTLET SIZE PRESSURE (bar) FLOW RATE (l/h) DIAMETER OF THROW (m) STREAM HEIGHT (m) DIAMETER OF THROW (m) DIAMETER OF THROW (m) DIAMETER OF THROW (m) STREAM HEIGHT (m) BROWN 0.9 mm 1.0 31 5.3 0.2 4.0 5.4 1.25 35 5.5 0.3 4.1 5.7 1.5 38 5.6 0.4 4.2 5.8 BLUE 1.0 mm 1.0 36 5.4 0.2 4.1 5.6 1.25 42 5.6 0.3 4.2 5.8 1.5 47 5.7 0.4 4.3 5.9 GREEN 1.3 mm 1.0 60 6.0 0.4 4.2 5.7 1.5 74 6.7 0.5 4.5 6.1 2.0 86 7.2 0.5 4.8 6.5 RED 1.5 mm 1.0 82 6.4 0.4 4.4 5.9 6.5 6.6 1.5 101 7.3 0.5 4.8 6.5 7.4 7.5 2.0 117 8.0 0.5 5.1 7.0 8.1 8.2 ORANGE 1.8 mm 1.0 109 6.8 0.4 1.5 133 7.7 0.5 2.0 154 8.4 0.5 GREY 2.0 mm 1.0 124 6.9 0.5 1.5 154 7.8 0.5 2.0 179 8.6 0.5 VARIABLE FLOW BLACK Adjustable to max 1.5 mm 1.0 0 - 77 0 - 6.3 0 - 0.4 1.5 0 - 94 0 - 7.2 0 - 0.4 2.0 0 - 105 0 - 7.9 0 - 0.4 YELLOW Adjustable to max 1.5 mm 1.0 0 - 77 0 - 6.3 0 - 0.4 1.5 0 - 94 0 - 7.2 0 - 0.4 2.0 0 - 105 0 - 7.9 0 - 0.4 PERFORMANCE GRAPH Recommended operating pressure is indicated by the rows highlighted in blue 23 SPRINKLERS Orbita Micro Sprinklers B2B www.distrijet.ch 022 84 000 45
Pressure Compensating Sprinklers Orbita PC Micro Sprinkler Assemblies Colours, Flow Rates & Orifice Sizes Base Colour Orange Blue Violet Green Red Flow Rate 30 l/h 40 l/h 50 l/h 55 l/h 80 l/h Base Outlet Size (mm) 1.25 1.30 1.45 1.55 1.65 PACKAGING Order Codes Packs 203124 203134 203144 203154 203164 Bulk 020312 020313 020314 020315 020316 Quantity per Bag Packs 25 Bulk 500 Bags per Carton Packs 100 Bulk 5 Weight per Carton (kg) Packs 14.2 Bulk 13.7 Base Inlet Connection 10-32 UNF Thread Dimensions Assembled (mm) Height 55 Width 32 Depth 17 Weight (g) 5.1 Material U.V. Stabilized Orbita PC 30 lph Orbita PC 55 lph Orbita PC Micro Sprinklers PERFORMANCE DATA PRESSURE COMPENSATING MICRO SPRINKLERS BASE COLOUR AND FLOW RATE PRESSURE (bar) FLOW RATE (l/h) DIAMETER OF THROW (m) STREAM HEIGHT (m) ORANGE 30 l/h 1.5 33.4 3.2 0.3 2.0 34.2 3.4 0.3 2.5 32.9 3.4 0.3 3.0 32.0 3.4 0.3 BLUE 40 l/h 1.5 38.1 3.6 0.3 2.0 41.2 3.8 0.3 2.5 41.6 3.8 0.3 3.0 43.2 3.8 0.3 VIOLET 50 l/h 1.5 46.0 3.8 0.4 2.0 49.4 4.0 0.4 2.5 48.6 4.0 0.4 3.0 49.6 4.0 0.4 GREEN 55 l/h 1.5 53.2 4.2 0.4 2.0 57.1 4.4 0.4 2.5 58.4 4.4 0.4 3.0 56.2 4.4 0.4 RED 80 l/h 1.5 68.0 5.4 0.4 2.0 78.9 5.8 0.4 2.5 84.8 6.0 0.4 3.0 84.2 6.0 0.4 Recommended Operating Pressure 1.5 bar to 3.0 bar - Tested 200 mm above Ground Level FEATURES and BENEFITS ● Pressure Compensating Micro Sprinklers with pre-defined flow rates ● Ideal where uniform flow rates and constant diameter of throw are required. ● Colour coded bases 30 lph (Orange), 40 lph (Blue, 50 lph (Violet), 55 lph (Green) and 80 lph (Red). APPLICATIONS ● Suitable for large areas that include garden beds, landscapes, vegetable gardens and agriculture applications. FILTRATION REQUIREMENTS ● Orange and Blue Bases: 130 microns (120 mesh) ● Violet, Green and Red Bases: 200 microns (80 mesh ) 24 Orbita PC Micro Sprinklers SPRINKLERS Les Spécialistes des Métiers de l’Eau et du Paysage
Micro Sprinklers STANDARD INVERTED FEATURES and BENEFITS ● Two Orbita micro sprinkler models available: Standard and Inverted ● Eight colour coded barbed bases to choose from for both models. ● Base colour identifies the flow rate. ● Strong “C” frame design allows for excellent water distribution uniformity. ● During rotation the spinner is supported between two bearings. ● The spinner on the inverted model has a cover that protects the bottom bearing from dust. APPLICATIONS ● Ideal for large areas that include garden beds, landscapes, vegetable gardens and agricultural applications. STANDARD INVERTED Orbita Micro Sprinkler with 4.5 mm Barbed Base Standard Inverted Base Colour Black Brown Blue Green Red Orange Grey White Black Brown Blue Green Red Orange Grey White Base Outlet Size (mm) 0.8 0.9 1.0 1.3 1.5 1.8 2.0 2.3 0.8 0.9 1.0 1.3 1.5 1.8 2.0 2.3 PACKAGING Order Codes Packs 208395 208405 208415 208425 208435 208445 208455 208465 208475 208485 208495 208505 208515 208525 208535 208545 Bulk 020839 020840 020841 020842 020843 020844 020845 020846 020847 020848 020849 020850 020851 020852 020853 020854 Quantity per Bag Packs 50 50 Bulk 500 500 Bags per Carton Packs 120 120 Bulk 12 12 Weight per Carton (kg) Packs 15.8 15.9 Bulk 15.3 15.4 Base Inlet Connection 4.5 mm Barb 4.5 mm Barb Dimensions Assembled (mm) Height 41.5 41.5 Width 33 33 Depth 12 12 Weight (g) 2.4 2.4 Material U.V. Stabilized 25 SPRINKLERS Orbita Micro Sprinklers B2B www.distrijet.ch 022 84 000 45
Inverted Micro Sprinkler Assemblies Inverted Orbita Micro Sprinkler Inverted Orbita Micro Sprinkler with Counter Weight, 500 mm FPVC and Adaptor Base Colour Black Brown Blue Green Red Orange Grey White Base Outlet Size 0.8 mm 0.9 mm 1.0 mm 1.3 mm 1.5 mm 1.8 mm 2.0 mm 2.3 mm PACKAGING Order Codes Packs 208552 208562 208572 208582 208592 208602 208612 208622 Bulk 020855 020856 020857 020858 020859 020860 020861 020862 Quantity per Bag Packs 10 Bulk 200 Bags per Carton Packs 20 Bulk 1 Weight per Carton (kg) Packs 15.8 Bulk 15.3 Base Inlet Connection 4.5 mm Barb Dimensions Assembled (mm) Height 550 Width 37 Depth 29 Weight (g) 59.5 Material U.V. Stabilized FEATURES and BENEFITS ● The Strong “C” frame design allows for excellent water distribution uniformity. ● Inverted Orbita Micro Sprinkler with barbed base. ● Eight colour coded bases to choose from ● Base colour identifies the flow rate. ● During rotation the spinner is supported between two bearings. ● The spinner on the inverted sprinkler has a cover that protects the bottom bearing from dust. ● A Counter Weight keeps the assembly stable and upright. The Counter Weight also aids with the insertion of the Winged Adaptor to the supply tube. ● 500 mm of Flexible PVC Tube allows the assembly to be suspended in a vertical position above plants and foliage. ● The Winged Adaptor may be inserted into the supply tube by a thread or barb. APPLICATIONS ● Agricultural applications and greenhouses. 26 Orbita Micro Sprinklers SPRINKLERS Les Spécialistes des Métiers de l’Eau et du Paysage
