Replacement Parts List 2022

hunterindustries.com EFFECTIVE JANUARY 2020 Supersedes all previous parts lists. Specifications are subject to change without notice. Replacement Parts List RESIDENTIAL & COMMERCIAL IRRIGATION | Built on Innovation ® hunterindustries.co EFFECTIVE JANUARY 2020 Supersedes all previous parts lists. Specifications are subject to change without notice. l i RESIDENTIAL & CO ERCIAL IRRIGATION | Built on Innovation ® B2B

PISCINE POMPAGE IRRIGATION FONTAINE - BASSIN PIÈCES-DÉTACHÉES ANNEXES BRUMISATION PRO. EQUIPEMENT B2B - RÉSERVÉ AUX PROFESSIONNELS

PARC & JARDINS ARROSAGE BRUMISATION ECLAIRAGE

IRRIGATION - FABRICANTS HUNTER SOLEM RAIN BIRD NAANDANJAIN ANTELCO TECO SRL

IRRIGATION - FABRICANTS PISCINE & FONTAINE - FABRICANTS IRRITEC PLASSON ZODIAC SPECK PENTAIR OASE DOSATRON ACIS HAYWARD

Les Spécialistes des Métiers de l’Eau et du Paysage ii Contents ROTORS ..............................................................1 PGJ-00: Gear-Driven Rotor .....................................................1 PGJ-04, 06, 12: Gear-Driven Rotor..........................................2 SRM-04, PGM-04, 06, 12: Gear-Driven Rotor (Before January 2021)..............................................................3 SRM-04: Gear-Driven Rotor (After January 2021)..................4 PGP ® -ADJ: Gear-Driven Rotor.................................................5 PGP-ATR: Gear-Driven Rotor ..................................................6 PGP-00: Gear-Driven Rotor ....................................................7 PGP-00-PRB: Gear-Driven Rotor............................................8 PGP-04 Ultra, PGP-06 ULTRA, PGP-12 CV Ultra: Gear-Driven Rotor ...................................................................9 PGP-04-PRB Ultra: Gear-Driven Rotor...................................10 I-20-00: Gear-Driven Rotor.....................................................11 I-20-00-PRB: Gear-Driven Rotor............................................12 I-20-04, I-20-06, I-20-12: Gear-Driven Rotor.........................13 I-20-04-PRB, I-20-06-PRB: Gear-Driven Rotor.....................14 I-25-04, 06: Gear-Driven Rotor...............................................15 I-40-04, 06: Gear-Driven Rotor ..............................................16 I-50-06: Gear-Driven Rotor.....................................................17 I-60: Gear-Driven Rotor...........................................................18 I-80: Gear-Driven Rotor...........................................................19 I-90: Gear-Driven Rotor ..........................................................20 ST SYSTEMS........................................................22 ST-90: Gear-Driven Rotor .......................................................22 STG-900: Gear-Driven Rotor...................................................23 ST-1600-HSB: Pop-Up & Gear Drive........................................24 ST-1700V: Valve-in-Head Pop-Up & Gear Drive ......................26 ST-173026-B Vault...................................................................28 ST-243636-B Vault ..................................................................29 NOZZLES.............................................................30 MP Rotator ® and Spray Nozzles..............................................30 SPRAYS...............................................................31 PSU-02, 04, 06: PS Ultra Spray Sprinkler ...............................31 PROS-02, 03, 04, 06, 12: Pro-Spray ® Sprinkler.......................32 PRS30-04, 06, 12: Pro-Spray Pressure-Regulated Spray Bodies ............................................................................33 PRS40-04CV, 06CV, 12CV: Pro-Spray Pressure-Regulated Spray Bodies ............................................................................34 VALVES ...............................................................35 SRV: Plastic Valve.....................................................................35 PGV-ASV: Plastic Valve, 6-Bolt Bonnet Design.......................36 PGV-ASV: Plastic Valve, 4-Bolt Bonnet Design.......................37 PGV-100G, 101G: Plastic Valve .................................................38 PGV Jar-Top: Plastic Valve .......................................................39 PGV-100A, 101A: Plastic Valve .................................................40 PGV-151, 201: Plastic Valve.......................................................41 HPV: Plastic Valve ....................................................................42 ICV-101G: Plastic Valve.............................................................43 ICV-151G & 201G: Plastic Valve .................................................44 ICV-301: Plastic Valve...............................................................45 IBV-101G: Brass Valve...............................................................46 IBV-151G & IBV-201G: Brass Valves ..........................................47 IBV-301G: Brass Valve..............................................................48 MICRO IRRIGATION ............................................49 ICZ-151: Drip Control Zone Kit ..................................................49 PCZ-101: Drip Control Zone Kit.................................................50 PCZ-101: Drip Control Zone Kit (Before January 2014)........... 51 ACZ-075: Drip Control Zone Kit...............................................52 ACZ-075: Drip Control Zone Kit (Before January 2014) ......... 53 ICZ-101: Drip Control Zone Kit..................................................54 ICZ-101-LF: Drip Control Zone Kit ............................................55 QUICK COUPLER VALVES ....................................56 HQ3RC: Quick Coupler Valve ...................................................56 HQ33RC, HQ33LRC, HQ33LRCR: Quick Coupler Valve...........57 HQ44RC, HQ44LRC, HQ44LRCR: Quick Coupler Valve..........58 HQ44RCAW, HQ44LRCAW, HQ44LRCAWR: Quick Coupler Valve ...........................................................................59 HQ5RC, HQ5LRC, HQ5LRCR: Quick Coupler Valve.................60 STANDARD CONTROLLERS .................................61 X2TM : Wi-Fi Capable Outdoor Mount Controller......................61 X-Core ® : Indoor/Outdoor Mount Controller............................62 Pro-C ® and PCC: Indoor/Outdoor Mount Controller...............63 ICC: Plastic Cabinet ..................................................................64 ICC: Metal Cabinet ...................................................................65 ICC Plastic Pedestal..................................................................66 I-Core ® : Plastic Cabinet............................................................67 I-Core: Metal Cabinet...............................................................68 I-Core: Plastic Pedestal............................................................69 HYDRAWISE® CONTROLLERS .............................70 HC: Wi-Fi Controller .................................................................70 HPC: Wi-Fi Controller...............................................................71 Pro-HC: Wi-Fi Controller..........................................................72 HCC: Wi-Fi Controller, Plastic Cabinet .....................................73 HCC: Wi-Fi Controller, Metal Cabinet ......................................74 CONTENTS

B2B www.distrijet.ch 022 84 000 45 iii Learn more. Visit hunterindustries.com CENTRALUSTMCONTROLLERS.............................75 ICC2: Plastic Cabinet................................................................75 ICC2: Metal Cabinet .................................................................76 ACC2 Decoder Replacement Parts A2C-75D-M, A2C-75D-P...............................................................................77 ACC2 Conventional Replacement Parts (A2C-1200-M, A2C-1200-P)............................................................................78 Plastic Pedestal (2017 to Present)...........................................79 IMMSTMONLINE CONTROLLERS..........................80 ACC: Pedestal Controller..........................................................80 ACC: Wall-Mount Controller ....................................................81 Communications Modules and Parts ......................................82 IMMS-CCC: IrrigationManagement andMonitoring System 83 IMMS-SI: IrrigationManagement andMonitoring System....84 IMMS-CI: IrrigationManagement andMonitoring System....85 DECODERS AND ACCESSORIES ...........................86 ICD-HP Components ...............................................................86 IDS: Plastic Pedestal ................................................................87 IDS: Controller Components ...................................................88 ROAM: Remote Control Unit...................................................89 ROAMXL: Remote Control Unit..............................................90 PSR: Pump Start Relay............................................................91 PSR-B: Pump Start Relay Booster ..........................................92 BATTERY-POWERED CONTROLLERS ..................93 NODE: Battery-Powered Controller ........................................93 NODE-BT: Bluetooth ® Battery-Powered Controller................94 XC Hybrid: Mounted Battery-Powered Plastic Controller.......95 XC Hybrid: Mounted Battery-Powered Stainless Steel Controller ........................................................................96 SENSORS ............................................................97 Mini-CliK ® : Rain Sensor ...........................................................97 Wired Rain-Clik ® : Rain Sensor.................................................98 Wireless Rain-Clik: Rain Sensor...............................................99 Solar Sync ® : ET Sensor.............................................................100 ET System ................................................................................101 ACCESSORIES .....................................................102 STATEMENT OF WARRANTY ...............................103

Les Spécialistes des Métiers de l’Eau et du Paysage PGJ-00: GEAR-DRIVEN ROTOR 1 ROTORS ITEM DESCRIPTION CATALOG NO. 1 Rubber Cover Black 537800SP Purple 537810 2 Nozzle Retention Screw 537900 3 Screen 272000 4 O-Ring 464500 5 Shrub Head Base 372800 6 Nozzle Rack (with 8 Nozzles) 538700SP ① ② ③ ④ ⑤ ⑥ ROTORS

B2B www.distrijet.ch 022 84 000 45 PGJ-04, 06, 12: GEAR-DRIVEN ROTOR 2 Learn more. Visit hunterindustries.com ROTORS ITEM DESCRIPTION CATALOG NO. 1 Rubber Cover Black 537800SP Black with Check Valve ID 537805 Purple with Check Valve ID 537810 2 Body Cap 537400 3 Riser Seal 538100SP 4 Spring Seat 326500SP 5 Nozzle Retention Screw 537900 6 Screen 272000 7 Check Valve 462078SP 8 Nozzle Rack (with 8 Nozzles) 538700SP 9 Body 4" (10 cm) 537300 6" (15 cm) 538400 12" (30 cm) 538500 ① ② ③ ④ ⑤ ⑥ ➆ ➇ ➈

Les Spécialistes des Métiers de l’Eau et du Paysage SRM-04, PGM-04, 06, 12: GEAR-DRIVEN ROTOR (BEFORE JANUARY 2021) 3 ROTORS ITEM DESCRIPTION CATALOG NO. 1 Body Cap 270700 2 Riser Seal 326400SP 3 Spring Seat 326500SP 4 Nozzle Retention Screw (Bag of 25) 463262 5 Screen (White) 272000 6 Check Valve 462078SP 7 Screen/Check Valve Assembly 302500 8 Nozzle Rack (with 0.50, 0.75, 1.0, 1.5, 2.0, 3.0) 327000SP ① ② ③ ④ ⑤ ⑥ ➆ ➇

B2B www.distrijet.ch 022 84 000 45 SRM-04: GEAR-DRIVEN ROTOR (AFTER JANUARY 2021) 4 Learn more. Visit hunterindustries.com ROTORS ITEM DESCRIPTION CATALOG NO. 1 Body Cap 537400 2 Riser Seal 538100SP 3 Spring Seat 326500SP 4 Nozzle Retention Screw 537900 5 Screen 272000 6 Check Valve 462078SP 7 Nozzle Rack (with 8 Nozzles) 538701SP 8 Body 4" (10 cm) 537300 ① ② ③ ④ ⑤ ⑥ ➆ ➇

Les Spécialistes des Métiers de l’Eau et du Paysage PGP ® -ADJ: GEAR-DRIVEN ROTOR 5 ROTORS ITEM DESCRIPTION CATALOG NO. 1 Blue Nozzle Set, 8 Nozzles 665300SP 2 Red Nozzle Set, 12 Nozzles 130900SP 3 Gray Low-Angle Nozzles, 7 Nozzles 233200SP 4 Setscrew 120300SP 5 Protective Rubber Cover Black (ADJ) (Fits Units Manufactured After 2/93) 269400SP 6 Standard Filter Screen (Black) 102600 7 Body Cap 103700SP 8 Riser Seal (100-Pack) 181500SP 9 Spring Seat 189900SP 10 Filter Screen/Check Valve Subassembly 142300SP 11 Body 4" (10 cm) 100200 ① ② ③ ④ ⑤ ⑥ ➆ ➇ ➈ ⑩ ⑪

B2B www.distrijet.ch 022 84 000 45 PGP-ATR: GEAR-DRIVEN ROTOR 6 Learn more. Visit hunterindustries.com ROTORS ITEM DESCRIPTION CATALOG NO. 1 Standard Nozzle Set (12), 25o Trajectory 130900SP 2 Low-Angle Nozzle Set (7), 13o Trajectory 233200SP 3 Setscrew 120300SP 4 Protective Rubber Cover - Black (ADJ) 269400SP 5 Standard Filter Screen (Black) 102600 6 Body Cap 103700SP 7 Riser Seal (100-Pack) 181500SP 8 Spring Seat 189900SP ① ② ③ ④ ⑤ ⑥ ➆ ➇

Les Spécialistes des Métiers de l’Eau et du Paysage 1.0 18' 2.0 18' 18'RADIUS 25'RADIUS .75 25' .5.50 18' 18' 3.3.0 25' 25' 3.0 2.0 .50 1.5 .75 1.1.5 25' 25' 1.0 7 ROTORS ITEM DESCRIPTION CATALOG NO. 1 Standard (8) and Low-Angle (4) Nozzle Set, Blue and Gray 782900SP 2 Short-Radius Nozzle Set (6) Black 466100SP 3 Nozzle Retainer Screw – Headed with Slot 180900 4 Rubber Cover Black 183600SP Purple 183605SP 5 Standard Filter Screen Black 102600 6 O-Ring 170600 7 Standard Shrub Head Base 106900 OPTIONS 8 Check Valve Spring 235000 9 Filter Screen/Check Valve Subassembly 142300SP 10 Shrub Head Base - Check Valve Model 234900 ① ② ③ ④ ⑤ ⑥ ➆ ➇ ➈ ⑩ PGP-00: GEAR-DRIVEN ROTOR

B2B www.distrijet.ch 022 84 000 45 1.0 18' 2.0 18' 18'RADIUS 25'RADIUS .75 25' .5.50 18' 18' 3.3.0 25' 25' 3.0 2.0 .50 1.5 .75 1.1.5 25' 25' 1.0 ITEM DESCRIPTION CATALOG NO. 1 Standard (8) and Low-Angle (4) Nozzle Set, Blue and Gray 782900SP 2 Short-Radius Nozzle Set (6) Black 466100SP 3 Nozzle Retainer Screw – Headed with Slot 180900 4 Rubber Cover Black 183600SP Purple 183605SP 5 Standard Filter Screen Black 102600 6 O-Ring 170600 7 Standard Shrub Head Base N/A OPTIONS 8 Check Valve Spring 235000 9 Filter Screen/Check Valve Subassembly 142300SP 10 Shrub Head Base with Pressure Regulator N/A ① ② ③ ④ ⑤ ⑥ ➆ ➇ ➈ ⑩ PGP-00-PRB: GEAR-DRIVEN ROTOR 8 Learn more. Visit hunterindustries.com ROTORS

Les Spécialistes des Métiers de l’Eau et du Paysage 1.0 18' 2.0 18' 18'RADIUS 25'RADIUS .75 25' .50 18' 3.0 25' 3.0 2.0 .50 1.5 .75 1.5 25' 1.0 PGP-04 ULTRA, PGP-06 ULTRA, PGP-12 CV ULTRA: GEAR-DRIVEN ROTOR 1.0 18' 2.0 18' 18'RADIUS 25'RADIUS .75 25' .5.50 18' 18' 3.3.0 25' 25' 3.0 2.0 .50 1.5 .75 1.1.5 25' 25' 1.0 18' 18'RADIUS 2.0 2.0 1.0 1.5 1.0 18' 0.5 18' 25'RADIUS 25' .75 25' 3.0 25' 1.5 .75 1.5 3.0 9 ROTORS ITEM DESCRIPTION CATALOG NO. 1 Standard (8) and Low-Angle (4) Nozzle Set, Blue and Gray 782900SP 2 Short-Radius Nozzle Set (6), Black 466100SP 3 Nozzle Retainer Screw – Headed with Slot 180900 4 Rubber Cover Assembly Black 183600SP Purple 183605SP 5 Filter Screen - Standard Model 102600 6 Check Valve Screen Assembly 142300SP 7 Body Cap 103700SP 8 Slip Washer - PGP-12-CV-Only 296100 9 Riser Seal 181500SP 10 Spring Seat 189900SP 11 Body 4" (10 cm) 100200 6" (15 cm) 434701 12" (30 cm) 179100 ① ② ③ ④ ⑤ ⑥ ➆ ➇ ➈ ⑩ ⑪

B2B www.distrijet.ch 022 84 000 45 1.0 18' 2.0 18' 18'RADIUS 25'RADIUS .75 25' .50 18' 3.0 25' 3.0 2.0 .50 1.5 .75 1.5 25' 1.0 PGP-04-PRB ULTRA: GEAR-DRIVEN ROTOR 1.0 18' 2.0 18' 18'RADIUS 25'RADIUS .75 25' .5.50 18' 18' 3.3.0 25' 25' 3.0 2.0 .50 1.5 .75 1.1.5 25' 25' 1.0 18' 18'RADIUS 2.0 2.0 1.0 1.5 1.0 18' 0.5 18' 25'RADIUS 25' .75 25' 3.0 25' 1.5 .75 1.5 3.0 ITEM DESCRIPTION CATALOG NO. 1 Standard (8) and Low-Angle (4) Nozzle Set, Blue and Gray 782900SP 2 Short-Radius Nozzle Set (6), Black 466100SP 3 Nozzle Retainer Screw – Headed with Slot 180900 4 Rubber Cover Assembly Black 183600SP Purple 183605SP 5 Filter Screen - Standard Model 102600 6 Check Valve Screen Assembly 142300SP 7 Body Cap 103700SP 8 Slip Washer - PGP-12-CV-Only 296100 9 Riser Seal N/A 10 Spring Seat 189900SP 11 Body with Pressure Regulator 4" (10 cm) N/A ① ② ③ ④ ⑤ ⑥ ➆ ➇ ➈ ⑩ ⑪ 10 Learn more. Visit hunterindustries.com ROTORS

Les Spécialistes des Métiers de l’Eau et du Paysage 1.0 18' 2.0 18' 18'RADIUS 25'RADIUS .75 25' .5.50 18' 18' 3.3.0 25' 25' 3.0 2.0 .50 1.5 .75 1.1.5 25' 25' 1. 0 11 ROTORS ITEM DESCRIPTION CATALOG NO. 1 Standard (8) and Low-Angle (4) Nozzle Set, Blue and Gray 782900SP 2 Standard (8) and Low-Angle (4) Nozzle Set, Navy Blue and Gray 356605SP 3 Short-Radius Nozzle Set (6), Black 466100SP 4 Nozzle Retainer Screw 180900 5 Rubber Cover Assembly Black 352476SP Purple 352478SP 6 Check Valve Spring 235000 7 Check Valve Screen Assembly 142300SP 8 O-Ring 170600 9 Shrub Head Base - Check Valve Model 234900 ① ② ③ ④ ⑤ ⑥ ➆ ➇ ➈ I-20-00: GEAR-DRIVEN ROTOR

B2B www.distrijet.ch 022 84 000 45 1.0 18' 2.0 18' 18'RADIUS 25'RADIUS .75 25' .5.50 18' 18' 3.3.0 25' 25' 3.0 2.0 .50 1.5 .75 1.1.5 25' 25' 1. 0 ITEM DESCRIPTION CATALOG NO. 1 Standard (8) and Low-Angle (4) Nozzle Set, Blue and Gray 782900SP 2 Standard (8) and Low-Angle (4) Nozzle Set, Navy Blue and Gray 356605SP 3 Short-Radius Nozzle Set (6), Black 466100SP 4 Nozzle Retainer Screw 180900 5 Rubber Cover Assembly Black 352476SP Purple 352478SP 6 Check Valve Spring 235000 7 Check Valve Screen Assembly 142300SP 8 O-Ring 170600 9 Shrub Head Base with Pressure Regulator N/A ① ② ③ ④ ⑤ ⑥ ➆ ➇ ➈ I-20-00-PRB: GEAR-DRIVEN ROTOR 12 Learn more. Visit hunterindustries.com ROTORS

Les Spécialistes des Métiers de l’Eau et du Paysage 13 ROTORS ITEM DESCRIPTION CATALOG NO. 1 Standard (8) and Low-Angle (4) Nozzle Set, Blue and Gray 782900SP 2 Standard (8) and Low-Angle (4) Nozzle Set, Navy Blue and Gray 356605SP 3 Short-Radius (6) Nozzle Set, Black 466100SP 4 Nozzle Retainer Screw 180900 5 Rubber Cover Assembly Black 352476SP Purple 352478SP 6 Filter Screen with Check Valve Assembly 142300SP 7 Body Cap 356000 8 Slip Washer I-20-04/I-20-06 102300 I-20-12 Only 296100 9 Riser Seal I-20-04 252500SP I-20-06 252500SP I-20-12 181500SP 10 Spring Seat I-20-04 227800 I-20-06 227800 I-20-12 189900SP 11 I-20 Shutoff Cap Assembly 296000 12 Body 4" (10 cm) 229200 6" (15 cm) 434700 12" (30 cm) 404200 ① ② ③ ④ ⑤ ⑥ ➆ ➇ ➈ ⑩ ⑪ ⑫ I-20-04, I-20-06, I-20-12: GEAR-DRIVEN ROTOR

B2B www.distrijet.ch 022 84 000 45 14 Learn more. Visit hunterindustries.com ROTORS ITEM DESCRIPTION CATALOG NO. 1 Standard (8) and Low-Angle (4) Nozzle Set, Blue and Gray 782900SP 2 Standard (8) and Low-Angle (4) Nozzle Set, Navy Blue and Gray 356605SP 3 Short-Radius (6) Nozzle Set, Black 466100SP 4 Nozzle Retainer Screw 180900 5 Rubber Cover Assembly Black 352476SP Purple 352478SP 6 Filter Screen with Check Valve Assembly 142300SP 7 Body Cap 356000 8 Slip Washer I-20-04/I-20-06 102300 9 Riser Seal I-20-04 252500SP I-20-06 252500SP 10 Spring Seat I-20-04 227800 I-20-06 227800 11 I-20 Shutoff Cap Assembly 296000 12 Body 4" (10 cm) N/A 6" (15 cm) N/A ① ② ③ ④ ⑤ ⑥ ➆ ➇ ➈ ⑩ ⑪ ⑫ I-20-04-PRB, I-20-06-PRB: GEAR-DRIVEN ROTOR

Les Spécialistes des Métiers de l’Eau et du Paysage 15 ROTORS ITEM DESCRIPTION CATALOG NO. 1 Nozzle Pack (1 each 7, 10, 15, 20, 25) 460010SP #4 – Yellow 463401SP #5 – White 463402SP #7 – Orange 463403SP #8 – Lt. Brown 463404SP #10 – Lt. Green 463405SP #13 – Lt. Blue 463406SP #15 – Gray 463407SP #18 – Red 463408SP #20 – Dk. Brown 463409SP #23 – Dk. Green 463410SP #25 – Dk. Blue 463411SP #28 – Black 463412SP 2 Nozzle Retainer Screw 333900 3 Filter Screen/Check Valve Assembly (White) 303700SP 4 Rubber Cover Screw (2 Required) 334000 5 Rubber Cover Assembly (Logo Base and Rubber Cover) Before 12/01/2013 Black 344605 Black SS 344635 Purple 344615 Purple SS 344640 Brown SS 344625 Rubber Cover Assembly (Logo Base and Rubber Cover) After 12/01/2013 Black 831000 Black SS 831003 Purple 831001 Purple SS 831004 Brown SS 831002 6 Body Cap Assembly (Before 12/01/2013 ) 341500 Body Cap Assembly (After 12/02/2013) 828500 7 Riser Seal Slip Washer Gray (after 12/02/2013) 827600 8 Riser Seal Black (before 12/01/2013) 221200 White (after 12/02/2013) 827500 9 Spring Seat Gray (after 12/02/2013) 827800 10 I-25/I-40/I-50 Shutoff Cap 223200 11 I-25/I-40/I-50 Blowout Cap – for 11/2" (3.8 cm) PVC Pipe 345400 12 Body 4" (10 cm) NPT 336405 4" (10 cm) BSP 336410 6" (15 cm) NPT 614705 6" (15 cm) BSP 614710 ① ② ③ ⑩ ④ ⑤ ⑥ ➆ ➇ ➈ ⑪ ⑫ I-25-04, 06: GEAR-DRIVEN ROTOR

B2B www.distrijet.ch 022 84 000 45 16 Learn more. Visit hunterindustries.com ROTORS ① ② ③ ④ ⑤ ⑥ ➆ ➇ ➈ ⑩ ⑫ ⑪ ⑬ ⑭ ⑮ ⑯ I-40-04, 06: GEAR-DRIVEN ROTOR ITEM DESCRIPTION CATALOG NO. 1 Adjustable Nozzle Pack (1 each 8, 10, 13, 15, 23, 25) 462458SP Nozzles (Bag of 25) #8 – Lt. Brown 461144 #10 – Lt. Green 461145 #13 – Lt. Blue 461146 #15 – Gray 461147 #23 – Dk. Green 461148 #25 – Dk. Blue 462436 Opposing Nozzle Pack (1 each 15, 18, 20, 23, 25, 28) 462459SP 2 Nozzle Retainer Screw 333900 3 Diffuser Pin 245400 4 Filter Screen/Check Valve Assembly (White) 303700SP 5 Model Number Button I-40 252705 6 Feature Designation Button Blank 252845 HS 252855 ON 252850 7 Rubber Cover Screw (2 Required) 334000 8 Rubber Cover Assembly (Includes Part 9) Black 828300 Brown 828301 Purple 828302 9 Rubber Cover Washer 828400 10 Body Cap Assembly STD 828700 ON 831400 11 Riser Seal Slip Washer Gray after 12/02/2013 827600 12 Riser Seal Black before 12/01/2013 221200 White after 12/02/2013 827500 13 Spring Seat Gray after 12/02/2013 827800 14 I-25/I-40/I-50 Shutoff Cap 223200 15 I-25/I-40/I-50 Blowout Cap – for 11/2" (3.8 cm) PVC Pipe 345400 16 Body 4" (10 cm) NPT 336405 4" (10 cm) BSP 336410 6" (15 cm) NPT 614705 6" (15 cm) BSP 614710

Les Spécialistes des Métiers de l’Eau et du Paysage I-50-06: GEAR-DRIVEN ROTOR 17 ROTORS ITEM DESCRIPTION CATALOG NO. 1 Adjustable Nozzle Pack (1 each 8, 10, 13, 15, 23, 25) 462458SP Nozzles (Bag of 25) #8 – Lt. Brown 461144 #10 – Lt. Green 461145 #13 – Lt. Blue 461146 #15 – Gray 461147 #23 – Dk. Green 461148 #25 – Dk. Blue 462436 Opposing Nozzle Pack (1 each 15, 18, 20, 23, 25, 28) 462459SP 2 Nozzle Retainer Screw 333900 3 Diffuser Pin 245400 4 Filter Screen/Check Valve Assembly (Gray) 993900 5 Screw Cover Button Blank 252845 ON 252850 6 Rubber Cover Screw (2 Required) 334000 7 Rubber Cover Assembly (Includes Part 8) Black 828300 Purple 828301 8 Rubber Cover Washer 253000 9 Body Cap Assembly STD 828700 ON 831400 10 Riser Seal Slip Washer Gray 827600 11 Riser Seal White 827500 12 Spring Seat Gray 827800 13 I-25/I-40/I-50 Shutoff Cap 223200 14 I-25/I-40/I-50 Blowout Cap – for 11/2" (3.8 cm) PVC Pipe 345400 15 Body 6" (15 cm) NPT 614705 6" (15 cm) BSP 614710 ① ② ③ ④ ⑤ ⑥ ➆ ➇ ➈ ⑩ ⑪ ⑫ ⑬ ⑭ ⑮

B2B www.distrijet.ch 022 84 000 45 I-60: GEAR-DRIVEN ROTOR ITEM DESCRIPTION CATALOG NO. 1 Body Cap Assembly 431700 2 Rubber Cover Screw (2 Required) 334000 3 Filter Screen Assembly (with Check Valve) 422200 4 Nozzle Package (Includes 7, 10, 13, 15, 18, 20) ADS 462373 36S 462374 18 Learn more. Visit hunterindustries.com ROTORS ① ② ③ ④

Les Spécialistes des Métiers de l’Eau et du Paysage ITEM DESCRIPTION CATALOG NO. 1 Screw – Logo Cap Retainer 189755 2 Rubber Logo Cap Assembly (Black) 255300 3 Yoke – Secondary Nozzle Housing 254500 4 O-Ring – Yoke Seal (2 Used) 252104 5 Screw – Primary Nozzle Retainer 180900 6 Seal Block Assembly with O-Ring 517100 7 O-Ring – Seal Block 549400 8 Spring – Riser Retraction 553700 9 Face Seal 256500 10 Ratchet Ring/Spring Seat 255000 11 Stator Base (for Plate #14) 256600 12 Plate – Stator Adjustment (Noz. #23–#53) 266500 13 Screen/Check Valve – Riser Inlet 271900 14 Primary Nozzles – Each #23 – Green 272101 #25 – Blue 272102 #33 – Gray 272103 #38 – Red 272104 #43 – Dk. Brown 272105 #48 – Dk. Green 272106 #53 – Dk. Blue 272107 15 Short-Range Nozzles – Each STD – Orange – Nozzles 803603 ON – Tan – Nozzles 803611 16 Mid-Range Nozzles – Each STD – Lt. Green – Nozzles 315313 ON – Lt. Blue – Nozzles 315311 17 Plug – Nozzle (Black) 315300 18 Yoke Assembly – Includes Items #3, #4, #15, #16, and #17 STD – For Primary Nozzles #23 – #53 863502 ON – For Primary Nozzles #25 – #53 863506 19 Nozzle Pack - #23 - #38 STD - #23 - #38 - Primary Nozzles, one Lt. Green mid-range nozzle, one Orange short range nozzle 460024 ON - #23 - #38 - Primary Nozzles, one Lt. Blue mid-range nozzle, one Tan short range nozzle 460055 20 Nozzle Pack - #43 - #53 STD - #43 - #53 - Primary Nozzles, one Lt. Green mid-range nozzle, one Orange short range nozzle 460025 ON - #43 - #53 - Primary Nozzles, one Lt. Blue mid-range nozzle, one Tan short range nozzle 460056 21 Snap Ring Assembly Black 450100 Purple 450105 22 Body Cap 943900 23 Body NPT - Gray 781301 BSP - Black 781302 ① ② ③ ④ ➄ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ⑭ ⑮ ⑯ ⑰ ⑱ 22 23 21 ⑲ ⑳ 19 ROTORS I-80: GEAR-DRIVEN ROTOR

B2B www.distrijet.ch 022 84 000 45 (Parts 18-21 are listed on the next page) ITEM DESCRIPTION CATALOG NO. 1 Rubber Cover Screw (1 Required) 351800SP 2 Rubber Cover Assembly ADV (Black) 529000 36V (Black) 528900 ARV (Purple) 529005 3RV (Purple) 528905 3 Body Cap Assembly 525000 4 Retainer Cap Screws (2 Required) 334000 5 Nozzle Retainer Screw (5 Required, not Shown) 333900 6 Retainer Cap (6/11 and After) – All 197200 7 Seal Block* 171710* 8 O-Ring Seal* 171600* 9 Retraction Spring* 171900* 10 Face Seal – Black* 406000* 11 Bumper – Gray* 171800* 12 Riser Assembly (Includes #4–11) ADV, ARV 525500 36V, 3RV 525400 13 Stator Adjustment Plate 052833 14 Screen Assembly 525200 15 Body NPT - Gray 525100 BSP - Black 525105 16 Nozzle Pack (1 Ea 25, 33, 38, 43, 48, 53, 63, 73) 461204 17 Primary Nozzles (Sold in Increments of 10) #25 – Lt. Blue 460011 #33 – Gray 464363 #38 – Red 464364 #43 – Dk. Brown 464365 #48 – Dk. Green 464366 #53 – Dk. Blue 464367 #63 – Black 464368 #73 – Orange 460012 *Parts 7 – 11 are required for the new I-90 seal replacement kit 20 Learn more. Visit hunterindustries.com ① ② ③ ④ ⑤ ⑤ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ⑭ ⑮ ROTORS I-90: GEAR-DRIVEN ROTOR

Les Spécialistes des Métiers de l’Eau et du Paysage (Pleaſe refer to the illuſtration on page 15) ITEM DESCRIPTION CATALOG NO. 18 Short Range Nozzle (5/11 and Prior) – All (Left, Black) (Sold in Increments of 10) 439100SP 19 Short-Range Nozzle (6/11 and After) (Left, Red) All Models (Sold in Increments of 10) 191800SP Mid-Range Nozzle (5/11 and Prior) (Sold InIincrements of 10) (Right, Green) ADV, ARV 439000SP (Right, BLue) 36V, 3RV 455400SP 20 Mid-Range Nozzle (6/11 and After) (Sold in Increments of 10) (Right, Green) ADV, ARV 195701SP (Right, BLue) 36V, 3RV 195704SP 21 Nozzle Plug (6/11 and After) (Left, Black) – All (Sold in Increments of 10) 195803SP Nozzle Plug (6/11 and After) (Right, Black) – All (Sold in Increments of 10) 195703SP 21 ⑯ ⑰ ⑯ ⑰ ⑱ ⑱ ⑲ ⑲ ⑲ ⑳ ⑳ ROTORS 21 I-90: GEAR-DRIVEN ROTOR (CONT. FROM PAGE 15) 21

B2B www.distrijet.ch 022 84 000 45 *Parts 7 – 11 are required for the new I-90 seal replacement kit ST-90: GEAR-DRIVEN ROTOR ITEM DESCRIPTION CATALOG NO. 1 Rubber Cover Screw (1 Required) 351800SP 2 Rubber Cover Assembly – Green 208900SP 3 Body Cap Assembly 525000 4 Retainer Cap Screws (2 Required) 334000 5 Nozzle Retainer Screw (5 Required, not Shown) 333900 6 Retainer Cap – All 197200SP 7 Seal Block* 171710* 8 O-Ring Seal* 171600* 9 Retraction Spring* 171900* 10 Face Seal – Black* 406000* 11 Bumper – Gray* 171800* 12 Riser Assembly (Includes #4 – 13) 517800 13 Screen Assembly 524600SP 14 Body NPT 525100 BSP 525105 15 Primary Nozzles (Sold in Increments of 10) #73 – Orange 460012 #83 – Tan 464369 16 Nozzle Plug (Left, Green) (Sold in Increments of 10) 195802 17 Nozzle Plug (Right, Green) (Sold in Increments of 10) 195702 22 Learn more. Visit hunterindustries.com ST SYSTEMS ① ② ③ ④ ⑤ ⑤ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ⑭ ⑯ ⑯ ⑰ ⑰ ⑮ ST SYSTEMS

Les Spécialistes des Métiers de l’Eau et du Paysage ITEM DESCRIPTION CATALOG NO. 1 Screw - Logo Cap Retainer 351800SP 2 Rubber Logo Cap - (Green) 242505SP 3 Snap Ring Assy. – (Black) 430700 4 Screw - Nozzle Retainer (5 used) 333900 5 Seal Block 171700 6 O-Ring - Seal 171600 7 Spring - Riser Retraction 171900 8 Face Seal - Black 406000 9 Bumper - Gray 171800 10 Riser Assembly - (Incl: Items 4 – 11) 517900 11 Screen - Riser Inlet 524600 12 Primary Nozzles (Sold in Increments of 10) #73 - Orange 460012 #83 - Tan 464369 13 Nozzle Plug (Left, Green) (Sold in Increments of 10) 195802 14 Nozzle Plug (Right, Green) (Sold in Increments of 10) 195702 15 Lid - Flange Compartment 493605 16 Tube Retainer - 1/8" (3 mm) Tubing 476000 17 Connector - 1/4" x 1/8" (6 mm x 3 mm) Tubing 402100 18 Tube Plug - 1/4" (6 mm) Tubing 052608 19 Tube Retainer - 1/4" (6 mm) Tubing 052610 20 Body Assembly, STG-900 (Incl: Items 16 - 22) 521000 21 Cap, Protective - Ssolenoid Wire Hole 643900 22 Cap, Protective 456800 23 Snap Ring Tool 251000SP 23 ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑮ ⑯ ⑰⑱ ⑲ ⑳ ST SYSTEMS STG-900: GEAR-DRIVEN ROTOR 21 22 23 ⑭ ⑬ ⑬ ⑭

B2B www.distrijet.ch 022 84 000 45 Illustration on next page ITEM DESCRIPTION CATALOG NO. 1 Primary Nozzle Retainer 502402SP 2 Primary Nozzle Kit #16 784800SP #18 784801SP #20 784802SP #22 784803SP #24 784804SP #26 784805SP 3 Secondary Nozzle Kit Female-Threaded Nozzle with Elbow 10005900SP Male-Threaded Nozzle 10006100SP 4 Speed Control Knob 510101SP 5 Gearbox Cover 502455 6 Turbine Assembly Kit 10006200SP 7 Reversing Kit 510164SP 8 Turret Inlet Kit 510167SP 9 Threaded Rotor Inlet 893600SP 10 Arc Rings (2) 205617SP 11 Gear Drive Assembly 881900SP 12 Rotor Cover Kit 204205SP 13 Upper Body Kit 502432SP 14 Riser Assembly 502432SP 15 Rubber Boot 502423 16 Lower Body Kit 502442SP 17 Gear-Drive Removal/Installation Tool 517600SP 24 Learn more. Visit hunterindustries.com ST SYSTEMS ST-1600-HSB: POP-UP & GEAR DRIVE

Les Spécialistes des Métiers de l’Eau et du Paysage ⑰ ⑭ ⑮ ⑯ 25 ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ➈ ⑩ ⑪ ⑫ ⑬ ST SYSTEMS ST-1600-HSB: POP-UP & GEAR DRIVE

B2B www.distrijet.ch 022 84 000 45 ST-1700V: VALVE-IN-HEAD POP-UP & GEAR DRIVE ITEM DESCRIPTION CATALOG NO. 1 Primary Nozzle Retainer 502402SP 2 Primary Nozzle Kit #16 784800SP #18 784801SP #20 784802SP #22 784803SP #24 784804SP 3 Secondary Nozzle Kit 10006100SP 4 Speed Control Knob 510101SP 5 Gearbox Cover 502455 6 Turbine Assembly Kit 10006200SP 7 Reversing Kit 510164SP 8 Turret Inlet Kit 510167SP 9 Threaded Rotor Inlet 893600SP 10 Arc Rings (2) 205617SP 11 Gear Drive Assembly 881900SP 12 Rotor Cover Kit 204205SP 13 Upper Body Kit 10006300SP 14 Solenoid Actuator Kit 10006400SP 15 Actuator Cover 10006500SP 16 Riser Assembly 502436SP 17 Rubber Boot 502423 18 Snap Ring 10006600SP 19 Valve-In-Head 10006700SP 20 Lower Body Kit 10006800SP 21 Gear Drive Removal/Installation Tool 517600SP 22 Valve-in-Head Removal Tool 10000100SP 23 Snap Ring Removal Tool 251000SP 26 Learn more. Visit hunterindustries.com ST SYSTEMS

Les Spécialistes des Métiers de l’Eau et du Paysage ⑭ ⑮ ⑯ ① ② ③ ④ ⑥ ⑦ ⑧ ➈ ⑩ ⑪ ⑫ ⑬ ⑰ ⑱ ⑲ ⑳ 21 22 ST-1700V: VALVE-IN-HEAD POP-UP & GEAR DRIVE 23 27 ⑤ ST SYSTEMS

B2B www.distrijet.ch 022 84 000 45 ITEM DESCRIPTION CATALOG NO. 1 Cover - Half - Circular Cover Side 953600 2 Cover - Half - Rotor Side 953800 3 Cover Circular - Small 910400 28 Learn more. Visit hunterindustries.com ① ② ③ ST SYSTEMS ST-173026-B VAULT

Les Spécialistes des Métiers de l’Eau et du Paysage ITEM DESCRIPTION CATALOG NO. 1 Cover - Half - Circular Cover Side 916200 2 Cover - Half - Rotor Side 916100 3 Cover - Circular - Small 910400 29 ① ② ③ ST SYSTEMS ST-243636-B VAULT

B2B www.distrijet.ch 022 84 000 45 MP ROTATOR ® AND SPRAY NOZZLES 4 2 1 3 5 ITEM DESCRIPTION CATALOG NO. 1 MP Rotator Filter Screen Very Fine - MP800SR90 MP8SCREENSP Fine - MP800SR360, MP815, MP1000, MP2000, MPStrips, MPCorner MPFSCREENSP Coarse - MP3000, MP3500 MPCSCREENSP 2 Spray Nozzle Filter Screen Fine - Gray Filter Screen 464716SP Coarse - Black Filter Screen 464717SP 3 Bubbler Filter Screen 207700SP 4 MP Adjustment Tool MPTOOL 5 Pressure Gauge Adapter MPADAPTERSP 6 Pressure Gauge with Adapter MPGAUGE 30 Learn more. Visit hunterindustries.com NOZZLES Nozzles

Les Spécialistes des Métiers de l’Eau et du Paysage 31 PSU-02, 04, 06: PS ULTRA SPRAY SPRINKLER ITEM DESCRIPTION CATALOG NO. 1 Body Cap Standard (Black) 162600 2 Spring Seat 181100 3 Ratchet Ring 162700 4 Filter Screen (4" (10 cm) and 6" (15 cm) Models Only) 162900SP 5 Check Valve Assembly 462237SP SPRAYS SPRAYS 1 2 3 4 5

B2B www.distrijet.ch 022 84 000 45 32 PROS-02, 03, 04, 06, 12: PRO-SPRAY ® SPRINKLER 5 ITEM DESCRIPTION CATALOG NO. 1 Snap-On Reclaimed Cap Purple PROSRCCAPSP 2 Body Cap Standard (Black) 458500SP With Check Valve ID (Black) 458505 Reclaimed Body Cap (Purple) 458520SP Reclaimed with Check Valve ID (Purple) 458525 Pro-Spray Shutoff Cap 213600SP 3 Riser Seal 472300SP 4 Ratchet Ring 629300 5 Check Valve Assembly 437400SP Learn more. Visit hunterindustries.com SPRAYS 1 2 3 4

Les Spécialistes des Métiers de l’Eau et du Paysage 33 PRS30-04, 06, 12: PRO-SPRAY PRESSURE-REGULATED SPRAY BODIES 1 5 ITEM DESCRIPTION CATALOG NO. 1 Snap-On Reclaimed Cap Purple PROSRCCAPSP 2 Body Cap Standard (Brown) 458551 With Check Valve ID (Brown) 458554 Reclaimed Body Cap with Check Valve ID (Purple) 458560 Pro-Spray Shutoff Cap 213600SP 3 Riser Seal 472300SP 4 Ratchet Ring 629300 5 Check Valve Assembly 437400SP SPRAYS 2 3 4

B2B www.distrijet.ch 022 84 000 45 34 2 3 4 5 ITEM DESCRIPTION CATALOG NO. 1 Snap-On Reclaimed Cap Purple PROSRCCAPSP 2 Body Cap Standard (Gray) with Check Valve ID 458556 Reclaimed with Check Valve ID (Purple) 458562 Pro-Spray Shutoff Cap 213600SP 3 Riser Seal 472300SP 4 Ratchet Ring 629300 5 Check Valve Assembly 437400SP Learn more. Visit hunterindustries.com SPRAYS PRS40-04CV, 06CV, 12CV: PRO-SPRAY PRESSURE-REGULATED SPRAY BODIES 1

Les Spécialistes des Métiers de l’Eau et du Paysage 35 SRV: PLASTIC VALVE 1 2 3 4 5 6 7 8 9 10 ITEM DESCRIPTION CATALOG NO. 1 Solenoid Assembly (Includes 2 & 3) AC Solenoid 606800 DC Solenoid 458200 2 O-Ring 262600 3 Solenoid Seal 364400 4 Bonnet Screw 427300 5 Bonnet without Flow Control 556100 6 Bonnet with Flow Control 556000 7 Diaphragm Spring 266000SP 8 Diaphragm Assembly 332100SP 9 Diaphragm Support Ring 331300SP 10 Flow Control Handle Black 269200 VALVES VALVES

B2B www.distrijet.ch 022 84 000 45 36 ITEM DESCRIPTION CATALOG NO. 1 Solenoid Assembly (Includes 2 & 3) AC Solenoid 606800 DC Solenoid 458200 2 O-Ring 262600 3 Solenoid Seal 364400 4 Bonnet Screw 427300 5 Bleed Screw 546700SP 6 Bonnet with Flow Control & Bleed Screw 187100 7 Diaphragm Spring 266000SP 8 Diaphragm Assembly 332100SP 9 Diaphragm Support Ring 331300SP 10 AVB/ASV Repair Kit ¾" (20 mm) 590307SP 1" (25 mm) 590306SP 11 Flow Control Handle Black 269200 Purple 269205 12 Purple Reclaimed ID Tag (10-Pack) LIT-700 PGV-ASV: PLASTIC VALVE, 6-BOLT BONNET DESIGN 11 DO NOT DRINK LIT-700 VALVES Learn more. Visit hunterindustries.com 1 2 3 4 5 7 8 9 12 6 10

Les Spécialistes des Métiers de l’Eau et du Paysage 37 PGV-ASV: PLASTIC VALVE, 4-BOLT BONNET DESIGN 1 2 3 4 5 7 8 9 11 6 10 ITEM DESCRIPTION CATALOG NO. 1 Solenoid Assembly (Includes 2 & 3) AC Solenoid 606800 DC Solenoid 458200 2 O-Ring 262600 3 Solenoid Seal 364400 4 Bonnet Screw 427300 5 Bleed Screw 546700SP 6 Bonnet with Flow Control & Bleed Screw 556000 7 Diaphragm Spring 266000SP 8 Diaphragm Assembly 332100SP 9 Diaphragm Support Ring 331300 10 AVB/ASV Repair Kit ¾" (20 mm) 590307SP 1" (25 mm) 590306SP 11 Flow Control Handle Black 269200 Purple 269205 VALVES

B2B www.distrijet.ch 022 84 000 45 38 ITEM DESCRIPTION CATALOG NO. 1 Solenoid Assembly (Includes 2 & 3) AC Solenoid 606800 DC Solenoid 458200 2 O-Ring 262600 3 Solenoid Seal 364400 4 Bonnet Screw 427300 5 Bleed Screw 546700SP 6 Bonnet without Flow Control with Bleed Screw 556100 7 Bonnet with Flow Control & Bleed Screw 556000 8 Diaphragm Spring 266000SP 9 Diaphragm Assembly 332100SP 10 Diaphragm Support Ring 331300 11 Flow Control Handle Black 269200 Purple 269205 12 Purple Reclaimed ID Tag (10-Pack) LIT-700 PGV-100G, 101G: PLASTIC VALVE DO NOT DRINK LIT-700 VALVES Learn more. Visit hunterindustries.com ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫

Les Spécialistes des Métiers de l’Eau et du Paysage 39 PGV JAR-TOP: PLASTIC VALVE 4 DO NOT DRINK LIT-700 VALVES ITEM DESCRIPTION CATALOG NO. 1 Solenoid Assembly (Includes 2 & 3) AC Solenoid 606800 DC Solenoid 458200 2 O-Ring 262600 3 Solenoid Seal 364400 4 Bonnet Ring 476100 5 Bleed Screw 546700SP 6 Bonnet Assembly (No Flow Control) 476700 7 Bonnet Assembly (With Flow Control) 476800 8 Diaphragm Spring 266000SP 9 Diaphragm Assembly 332100SP 10 Diaphragm Support Ring 331300SP 11 Flow Control Handle Black 269200 Purple 269205 12 Purple Reclaimed ID Tag (10-Pack) LIT-700 ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫

B2B www.distrijet.ch 022 84 000 45 40 ITEM DESCRIPTION CATALOG NO. 1 Solenoid Assembly (Includes 2 & 3) AC Solenoid 606800 DC Solenoid 458200 2 O-Ring 262600 3 Solenoid Seal 364400 4 Bonnet Screw 427300 5 Bleed Screw 546700SP 6 Bonnet with Flow Control & Bleed Screw 556000 7 Bonnet without Flow Control with Bleed Screw 556100 8 Diaphragm Spring 266000SP 9 Diaphragm Assembly 332100SP 10 Diaphragm Support Ring 331300P 11 Flow Control Handle Black 269200 Purple 269205 12 Purple Reclaimed ID Tag (10-Pack) LIT-700 PGV-100A, 101A: PLASTIC VALVE DO NOT DRINK LIT-700 VALVES Learn more. Visit hunterindustries.com ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫

Les Spécialistes des Métiers de l’Eau et du Paysage 41 PGV-151, 201: PLASTIC VALVE DO NOT DRINK LIT-700 VALVES ITEM DESCRIPTION CATALOG NO. 1 Solenoid Assembly (Includes 2 & 3) AC Solenoid 606800 DC Solenoid 458200 2 O-Ring 262600 3 Solenoid Seal 364400 4 Bleed Screw Assembly (Qty. 5) 1½" (40 mm) 427000SP 2" (50 mm) 427100SP 5 Flow Control Handle (Qty. 5) Black 607100SP Purple 607105SP 6 Bonnet Screw 472800 7 Bonnet 1½" (40 mm) 414000SP 2" (50 mm) 415500SP 8 Flow Control Stem Assembly (Includes stem, stem nut, O-Ring) 1½" (40 mm) 421500SP 2" (50 mm) 414600SP Flow Control Stem 1½" (40 mm) 606900 2" (50 mm) 607000 Flow Control Stem Nut 1½" (40 mm) 413000 2" (50 mm) 414700 Flow Control Stem O-Ring 1½" & 2" (40 mm & 50 mm) 412900 9 Spring 1½" (40 mm) 412300 2" (50 mm) 414200 10 Diaphragm Assembly 1½" (40 mm) 414100SP 2" (50 mm) 415600SP 11 Diaphragm Support 1½" (40 mm) 413100 2" (50 mm) 414800 12 Body Plug without O-Ring 1½" NPT (40 mm) 413800 1½" BSP (40 mm) 413805 2" NPT (50 mm) 415300 2" BSP (50 mm) 415305 13 O-Ring for Plug 1½" (40 mm) 413900 2" (50 mm) 415400 14 Purple Reclaimed ID Tag (10-Pack) LIT-700 ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ 14

B2B www.distrijet.ch 022 84 000 45 42 ITEM DESCRIPTION CATALOG NO. 1 Solenoid Assembly (Includes 2 & 3) AC Solenoid 606800 DC Solenoid 458200 2 O-Ring 262600 3 Solenoid Seal 364400 4 Bonnet Screw 266100 5 Bonnet with Flow Control UNAVAILABLE 6 Bonnet without Flow Control 266602SP 7 Diaphragm Spring 266000SP 8 Diaphragm Assembly 266902SP 9 Diaphragm Support Ring 265000SP 10 Flow Control Handle Black 269200 Purple 269205 HPV: PLASTIC VALVE 1 2 3 4 6 5 7 8 9 10 VALVES Learn more. Visit hunterindustries.com

Les Spécialistes des Métiers de l’Eau et du Paysage 43 ITEM DESCRIPTION CATALOG NO. 1 Solenoid Assembly (Includes Parts 2 & 3) AC Solenoid 606800 DC-Latching Solenoid 458200 2 Solenoid O-Ring 262600 3 Solenoid Seal 364400 4 Bonnet Assembly (Includes Parts 5-8, 11) 900100SP 5 Bleed Screw (10-Pack) 900300SP 6 Flow Control Knob Standard 899600SP Purple Reclaimed 899605SP 7 E-Clip Retainer 387200SP 8 Bonnet -- 9 Bonnet Bolts 669000SP 10 Diaphragm Spring 386700SP 11 Flow Control Stem Assembly (Includes Parts 12-14) 900200SP Flow Control Stem -- Flow Control Stem Nut -- Flow Control Stem O-Ring -- 12 Diaphragm Assembly with Filter Sentry ® 461503SP 13 Diaphragm Support Ring 711900 14 Valve Body -- 15 Filter Sentry Tag (10-Pack) 700392SP 16 Purple Reclaimed ID Tag (10-Pack) LIT-700 IBV-101G: BRASS VALVE 1 2 3 5 8 12 13 6 7 11 10 FILTER SENTRY ™ INSTALLED LIT-301 P/N:700392 16 15 DO NOT DRINK LIT-700 VALVES 9 14 4

B2B www.distrijet.ch 022 84 000 45 44 ITEM DESCRIPTION CATALOG NO. 1 Solenoid Assembly (Includes 2 & 3) AC Solenoid 833400SP DC Solenoid 458200 2 Solenoid O-Ring 262600 3 Solenoid Seal 364400 4 Bonnet Assembly (Includes Parts 5-8, 11) 900800SP 5 Bleed Screw (10-Pack) 901000SP 6 Flow Control Knob Standard 899600SP Purple Reclaimed 899605SP 7 E-Clip Retainer (10-Pack) 371600SP 8 Bonnet -- 9 Bonnet Bolts 669000 10 Diaphragm Spring 365400SP 11 Flow Control Stem Assembly (Includes Parts 12-14) 900900SP Flow Control Stem -- Flow Control Stem Nut -- Flow Control Stem O-Ring -- 12 Diaphragm Assembly Filter Sentry 676901SP 13 Diaphragm Assembly Purple Reclaimed 676902SP 14 Diaphragm Support Ring 365900SP 15 Valve Body -- 16 Filter Sentry Tag (10-Pack) 700392SP 17 Purple Reclaimed ID Tag (10-Pack) LIT-700 IBV-151G & IBV-201G: BRASS VALVES 1 2 3 4 5 8 11 6 7 9 12 10 FILTER SENTRY ™ INSTALLED LIT-301 P/N:700392 14 15 DO NOT DRINK LIT-700 VALVES 17 16 13 Learn more. Visit hunterindustries.com

Les Spécialistes des Métiers de l’Eau et du Paysage 45 ITEM DESCRIPTION CATALOG NO. 1 Solenoid Assembly (Includes Parts 2 & 3) AC Solenoid 606800 DC Latching Solenoid 458200 2 Solenoid O-Ring 262600 3 Solenoid Seal 364400 4 Bonnet Assembly (Includes Parts 5-7, 10) 901700SP 5 Bleed Screw (10-Pack) 902000SP 6 Flow Control Knob Standard 899600SP Purple Reclaimed 899605SP 7 Bonnet -- 8 Bonnet Bolts 669000 9 Diaphragm Spring 518000SP 10 Flow Control Stem Assembly (Includes Parts 12-14) 901900SP Flow Control Stem -- Flow Control Stem Nut -- Flow Control Stem O-Ring -- 11 Diaphragm Assembly Filter Sentry 518905 12 Diaphragm Support Ring 514600 13 Valve body -- 14 Filter Sentry Tag (10-Pack) 700392SP 15 Purple Reclaimed ID Tag (10-Pack) LIT-700 IBV-301G: BRASS VALVE FILTER SENTRY ™ INSTALLED LIT-301 P/N:700392 15 DO NOT DRINK LIT-700 VALVES 1 2 3 5 9 10 14 6 7 8 4 11 12 13

B2B www.distrijet.ch 022 84 000 45 46 14 15 7 ICV-101G: PLASTIC VALVE 1 2 3 4 5 8 11 13 6 9 10 12 FILTER SENTRY ™ INSTALLED LIT-301 P/N:700392 DO NOT DRINK LIT-700 VALVES ITEM DESCRIPTION CATALOG NO. 1 Solenoid Assembly (Includes 2 & 3) AC Solenoid 606800 DC Solenoid 458200 2 O-Ring 262600 3 Solenoid Seal 364400 4 Bleed Assembly 561400 5 Bonnet Bolt 386900 6 Flow Control Knob Black 561200SP Purple 561205SP 7 E-Clip Retainer 387200 8 Bonnet 387700 9 Flow Control Stem Assembly (Includes stem, stem nut, O-Ring) 387900 Flow Control Stem 560900 Flow Control Stem Nut 386000 Flow Control Stem O-Ring 387100 10 Spring 386700 11 Diaphragm Assembly –Standard 387800SP 12 Diaphragm Assembly with Filter Sentry Mechanism 461503SP 13 Diaphragm Support Ring 711900 14 Filter Sentry® Tag, Yellow (10-Pack) 700392SP 15 Purple Reclaimed ID Tag (10-Pack) LIT-700 Learn more. Visit hunterindustries.com

Les Spécialistes des Métiers de l’Eau et du Paysage 47 15 16 7 ICV-151G & 201G: PLASTIC VALVE 1 2 3 4 5 8 11 13 6 9 10 12 FILTER SENTRY ™ INSTALLED LIT-301 P/N:700392 DO NOT DRINK LIT-700 VALVES ITEM DESCRIPTION CATALOG NO. 1 Solenoid Assembly (Includes 2 & 3) AC Solenoid 606800 DC Solenoid 458200 2 O-Ring 262600 3 Solenoid Seal 364400 4 Bleed Assembly 561500SP 5 Bonnet Bolt 366700 6 Flow Control Knob Black 561200SP Purple 561205SP 7 E-Clip Retainer 387200 8 Bonnet 380600SP 9 Flow Control Stem Assembly (Includes stem, stem nut, O-Ring) 374600SP 10 Spring 365400SP 11 Diaphragm Assembly – Standard 460026SP 12 Diaphragm Assembly with Filter Sentry Mechanism 460027SP 13 Diaphragm Assembly, Reclaimed 676902SP 14 Diaphragm Support Ring 365900SP 15 Filter Sentry Tag, Yellow (10-Pack) 700392SP 16 Purple Reclaimed ID Tag (10-Pack) LIT-700 14

B2B www.distrijet.ch 022 84 000 45 48 14 15 ICV-301: PLASTIC VALVE 1 3 2 4 5 9 16 11 6 7 12 13 8 10 FILTER SENTRY ™ INSTALLED LIT-301 P/N:700392 DO NOT DRINK LIT-700 VALVES ITEM DESCRIPTION CATALOG NO. 1 Solenoid Assembly (Includes 2 & 3) AC Solenoid 606800 DC Solenoid 458200 2 O-Ring 262600 3 Solenoid Seal 364400 4 Bleed Screw Assembly, Male Threads (2014 and Older) N/A Bleed Screw Assembly, Female Threads (2015 and Newer) 836200 5 Flow Control Knob (2014 and Older) Black 515000 Purple N/A Flow Control Knob, (2015 and Newer) Black 836500 Purple 836501SP 6 Bonnet Bolt 386900 7 Bonnet Assembly (incl. 4, 5, 8) 856300SP 8 Flow Control Stem Assembly, Female Threads (2014 and Older) N/A Flow Control Stem Assembly, Male Threads (2015 and Newer) 836200 9 Diaphragm Spring 518000 10 Diaphragm Assembly 518900SP 11 Filter Sentry ® Diaphragm Assembly 518905SP 12 Diaphragm Support 514600 13 Port Plug Assembly (includes O-Ring) NPT 514900 BSP 514905 14 Filter Sentry Tag, Yellow (10-Pack) 700392SP 15 Purple Reclaimed ID Tag (10-Pack) LIT-700 16 Diaphragm Filter Screen 365200 Learn more. Visit hunterindustries.com

Les Spécialistes des Métiers de l’Eau et du Paysage 49 VALVES ITEM DESCRIPTION CATALOG NO. 1 Swivel Adapter 253500SP 2 O-Ring (25-pack) 262600SP ACCU SYNC 1 2

B2B www.distrijet.ch 022 84 000 45 50 10 ICZ-101: DRIP CONTROL ZONE KIT 9 DO NOT DRINK LIT-700 ITEM DESCRIPTION CATALOG NO. 1 Solenoid Assembly (Includes Parts 2 & 3) AC Solenoid 606800 DC Latching Solenoid 458200 2 O-Ring 262600 3 Solenoid Seal 364400 4 ICV-101G-FS Valve ICV-101G-FS 5 1" (25 mm) M x 1" (25 mm) M NPT Wye Filter Assembly HY-100 6 Stainless Steel Screen 150 Mesh 606200SP 7 Flush Cap with O-Ring 651900 8 1" (25 mm) F x 1" (25 mm) F NPT Pressure Regulator 25 PSI (1.7 bar; 170 kPa) 606000 40 PSI (2.8 bar; 280 kPa) 652100 9 O-Ring for HY-100 154900 10 Filter Bonnet Black 133800 Filter Bonnet, Reclaimed Purple 133801 11 Purple Reclaimed ID Tag (10-Pack) LIT-700 11 1 2 3 4 5 6 7 8 10 Learn more. Visit hunterindustries.com MICRO IRRIGATION

Les Spécialistes des Métiers de l’Eau et du Paysage 51 ITEM DESCRIPTION CATALOG NO. 1 Solenoid Assembly (Includes Parts 2 & 3) AC Solenoid 606800 DC Latching Solenoid 458200 2 O-Ring 262600 3 Solenoid Seal 364400 5 ICV-101G Valve ICV-101G 6 Filter/Regulator Assembly, 1" (25 mm) x 3/4" (20 mm) HFR-100-075-XX (XX is 25 or 40 PSI; 1.7 or 2.8 bar; 170 or 280 kPa) 7 Stainless Steel Screen 150 Mesh 809300SP 8 Flush Cap with O-Ring 651900 9 O-Ring for HFR-100-075 154900 10 Filter Bonnet (No Cap) Black 133800 11 Bonnet, Filter, Reclaimed Purple 133801 1 2 3 5 9 6 7 8 ICZ-101-LF: DRIP CONTROL ZONE KIT 11 MICRO IRRIGATION

B2B www.distrijet.ch 022 84 000 45 52 ICZ-151: DRIP CONTROL ZONE KIT ITEM DESCRIPTION CATALOG NO. 1 Filter Assembly with 150 Mesh SS Screen HY-151 2 Spare - Stainless Steel Screen 150 Mesh (Standard) HY151SCREEN150 Spare - Stainless Steel Screen 120 Mesh HY151SCREEN120 Spare - Stainless Steel Screen 80 Mesh HY151SCREEN080 3 Spare - Disc 125 Micron (120 Mesh) HY151DISC120 4 Flush Valve 995500SP 5 Flush Cap with O-Ring 651900 6 Senninger 2" (50 mm) Inlet/Outlet Regulator at 40 PSI (2.8 bar; 280 kPa) PRU-40 7 ICV-151G-FS Valve ICV-151G-FS Learn more. Visit hunterindustries.com MICRO IRRIGATION MICRO IRRIGATION 7 6 4 3 5 1 2

Les Spécialistes des Métiers de l’Eau et du Paysage 53 ICZ-201: DRIP CONTROL ZONE KIT ITEM DESCRIPTION CATALOG NO. 1 Filter Assembly with 150 Mesh Stainless Steel Screen HY-201 Filter Assembly with 120 Mesh Stainless Steel Disc HY-201-D 2 Spare Stainless Steel Screen, 150 Mesh (Standard) HY201SCREEN150 Spare Stainless Steel Screen, 120 Mesh HY201SCREEN120 Spare Stainless Steel Screen, 80 Mesh HY201SCREEN080 3 Spare Spare 125-Micron Disc, 120 Mesh HY201DISC120 4 Flush Valve (Optional) 995500SP 5 Flush Cap with O-Ring 651900 6 Senninger 2" (50 mm) Inlet/Outlet Regulator at 40 PSI (2.8 bar; 280 kPa) PRU-40 7 ICV-201G-FS Valve ICV-201G-FS 7 6 4 3 5 1 2 MICRO IRRIGATION

B2B www.distrijet.ch 022 84 000 45 54 4 1 2 3 5 9 6 7 8 PCZ-101: DRIP CONTROL ZONE KIT 11 DO NOT DRINK LIT-700 10 ITEM DESCRIPTION CATALOG NO. 1 Solenoid Assembly (Includes Parts 2 & 3) AC Solenoid 606800 DC Latching Solenoid 458200 2 O-Ring 262600 3 Solenoid Seal 364400 4 Handle Flow Control 269200 5 PGV-101G Valve PGV101G 6 Filter/Regulator Assembly HFR-100-075-25 HFR-100-075-40 7 Stainless Steel Screen - 150 Mesh 809300SP 8 Flush Cap with O-Ring 651900 9 O-Ring for HFR-100-075 154900 10 Filter Bonnet (No Cap) 133800 Bonnet, Reclaimed Purple 133801 11 Purple Reclaimed ID Tag (10-Pack) LIT-700 Learn more. Visit hunterindustries.com MICRO IRRIGATION

Les Spécialistes des Métiers de l’Eau et du Paysage 55 4 1 2 3 5 9 6 7 8 PCZ-101: DRIP CONTROL ZONE KIT (BEFORE JANUARY 2014) 10 ITEM DESCRIPTION CATALOG NO. 1 Solenoid Assembly (Includes Parts 2 & 3) AC Solenoid 606800 DC Latching Solenoid 458200 2 O-Ring 262600 3 Solenoid Seal 364400 4 Handle Flow Control Black 269200 5 PGV-101G Valve PGV-101G 6 1" (25 mm) M x ¾" (20 mm) M NPT Wye Filter Assembly HY-100-075-XX (XX is 25 or 40 PSI; 1.7 or 2.8 bar; 170 or 280 kPa) 7 Stainless Steel Screen 150 Mesh 606200SP 8 Flush Cap with O-Ring 651900 9 O-Ring for HY-100 154900 10 Filter Bonnet (No Cap) Black 133800 MICRO IRRIGATION

B2B www.distrijet.ch 022 84 000 45 56 6 7 8 9 ACZ-075: DRIP CONTROL ZONE KIT 10 11 DO NOT DRINK LIT-700 ITEM DESCRIPTION CATALOG NO. 1 Solenoid Assembly (Includes Parts 2 & 3) AC Solenoid 606800 DC Latching Solenoid 458200 2 O-Ring 262600 3 Solenoid Seal 364400 4 Handle Flow Control Black 269200 5 ¾" (20 mm) PGV-ASV Valve PGV-075-ASV 6 Filter/Regulator Assembly 25 PSI (1.7 Bar; 172 kPa) HFR-075-25 40 PSI (2.8 Bar; 276 kPa) HFR-075-40 7 Stainless Steel Screen 150 Mesh 809300SP 8 Flush Cap with O-Ring 651900 9 O-Ring for HFR-075 154900 10 Filter Bonnet (No Cap) Black 133800 Bonnet, Filter, Reclaimed Purple 133801 11 Purple Reclaimed ID Tag (10-Pack) LIT-700 Learn more. Visit hunterindustries.com 2 3 5 1 2 3 4 5 1 5 MICRO IRRIGATION

Les Spécialistes des Métiers de l’Eau et du Paysage 57 ITEM DESCRIPTION CATALOG NO. 1 Solenoid Assembly (Includes Parts 2 & 3) AC Solenoid 434100 DC Latching Solenoid 458200 2 O-Ring 262600 3 Solenoid Seal 364400 4 Handle Flow Control Black 269200 5 ¾" (20 mm) PGV-ASV Valve PGV-075-ASV 6 ¾" (20 mm) M x ¾" (20 mm) M NPT Wye Filter Assembly HY-075 7 Stainless Steel Screen 150 Mesh 606200 8 Flush Cap with O-Ring 651900 9 O-Ring for HY-100 154900 10 Filter Bonnet (No Cap) Black 133800 11 Purple Reclaimed ID Tag LIT-700 12 Bonnet, Filter, Reclaimed Purple 133801 ACZ-075: DRIP CONTROL ZONE KIT (BEFORE JANUARY 2014) 12 10 2 3 4 5 7 9 1 5 4 1 DO NOT DRINK LIT-700 11 2 3 4 5 6 7 8 9 1 MICRO IRRIGATION

B2B www.distrijet.ch 022 84 000 45 58 Learn more. Visit hunterindustries.com MICRO IRRIGATION 10 IBZ-101: BRASS VALVE DRIP CONTROL ZONE KIT 9 ITEM DESCRIPTION CATALOG NO. 1 Solenoid Assembly (Includes Parts 2 & 3) AC Solenoid 606800 DC-Latching Solenoid 458200 2 O-Ring 262600 3 Solenoid Seal 364400 4 IBV-101G-FS Valve IBV-101G-FS 5 1" (25 mm) M x 1" (25 mm) M NPT Wye Filter Assembly HY-100 6 Stainless Steel Screen 150 Mesh 606200SP 7 Flush Cap with O-Ring 651900 8 1" (25 mm) F x 1" (25 mm) F NPT Pressure Regulator 25 PSI (1.7 bar; 170 kPa) 606000 40 PSI (2.8 bar; 280 kPa) 652100 9 O-Ring for HY-100 154900 10 Filter Bonnet Black 133800 1 2 3 4 5 6 7 8 10
